Wire Composer

No-code visual pipeline builder: describe a workflow in plain English, get an executable multi-step graph backed by the Anakin Wire API. No user accounts — runs use your API keys (server-side for Wire; session-only for optional credentials).

Live app

Features

• NL → DAG — POST /api/parse-pipeline (DeepSeek) builds nodes, edges, and field mappings; sidebar Examples load verified curated templates (Polymarket, GitHub, Product Hunt, Airbnb).
• Visual composer — React Flow canvas, minimap, node inspector, run status bar.
• Built-in steps — wire.data.extract, wire.condition.compare, wire.filter.reviews, wire.ai.transform, wire.trigger.webhook.
• Streaming runs — Topological execution + SSE (lib/pipeline-executor.ts); inspector overrides win over upstream mappings.
• Persistence — Save / load pipelines in Vercel KV.
• Schedule & webhooks — Cron + deployable webhook URLs.

Stack

Project layout

app/
  composer/          # Main builder
  pipelines/         # Library + saved pipeline view
  api/               # parse-pipeline, run-pipeline, pipelines, wire, cron, webhooks
components/composer/ # Canvas, NL panel, examples, inspector, run bar
lib/                 # executor, examples, merge/resolve inputs, Wire client
hooks/               # useWireActions, usePipelineParser, usePipelineRunner
scripts/             # Local smoke tests (node --env-file=.env.local scripts/…)

Getting started

Prerequisites

• Node.js 20+
• DeepSeek API key
• Anakin API key
• Vercel KV (optional locally; required for save/library)

Environment

Create .env.local:

DEEPSEEK_API_KEY=sk-...
ANAKIN_API_KEY=ak-...

KV_URL=redis://...
KV_REST_API_URL=https://...
KV_REST_API_TOKEN=...
KV_REST_API_READ_ONLY_TOKEN=...

CRON_SECRET=...
ANAKIN_CREDENTIAL_ID=...   # optional Wire identity UUID

NEXT_PUBLIC_APP_URL=http://localhost:3000

Commands

npm install
npm run dev          # http://localhost:3000
npm run build
npm run start
npm run diagnose:anakin

Local tests

node --env-file=.env.local scripts/test-sanitize-wire-params.mjs
node --env-file=.env.local scripts/test-example-templates.mjs
node --env-file=.env.local scripts/test-parse-pipeline-local.mjs

Routes

API (summary)

Deployed on Google Cloud Run (us-central1). Local deploy scripts (deploy_run_only.ps1, Dockerfile) are gitignored — use them from your machine with .env.local and gcloud configured.

Built With

• next.js
• typescript
