Inspiration
Our team was interested in developing a system that would ease the process of interior design. The idea came to us when we were thinking of biulding drone that could draw on a wall. This then evolved to the idea of having a vehicle with the capability of painting on a wall.
What it does
This device/vehicle using motion in two axes to draw on a wall. Being a vehicle it can move and position itself appropriately against a wall before beginning the printing/painting process.
How I built it
We designed it to be similar to the two axis design of a 3D printer but in the vertical orientation as opposed to the horizontal orientation.
Challenges We Ran Into
Deciding on the mechanism for motion in the vertical direction(z-axes) was quite the challenge because each of implementation ideas was unprecedented in our experiences. Delta-arm robots are similar but use gravity to maintain position, we had to figure out how to move as accurately in a vertical space.
Accomplishments that I'm proud of
We got the two axis design to move and follow code to draw; considering the scope of our project, I was impressed.
What I learned
The team members developed further skills in a very wide range of disciplines from OpenCV to heavy machining.
What's next for WallPaint
Some features mentioned in YouTube video: https://youtu.be/YxOCw7u1ZJE
Built With
- 3dprinting
- 80/20
- arduino
- autodesk
- camera
- google-cloud
- laser-cutting
- opencv
- raspberry-pi
- solidworks
