  Varuna Street-Level Urban Flood Nowcasting System

VARUNA

Street-level urban flood nowcasting digital twin. SIH 2026, problem statement SIH26085 (Ministry of Earth Sciences). Team SummitSquard.

"Every street. Three hours early."

VARUNA is a self-correcting digital twin of a city's water: sky, surface and sewer. It turns Doppler-radar rainfall into street-by-street depth forecasts for the next three hours, learns the city's hidden drains from every flood it sees, and tells emergency services which street will be impassable, when, and how to get around it.

Everything in the prototype runs live: real Mumbai terrain and roads from open data, a reconstructed replay of 2 July 2019, simplified-but-real physics for the surface and the drains, a learning drain map, sub-second what-if, and routes for an ambulance. Every simplification is labelled on screen and listed in docs/SIMPLIFICATIONS.md.

Quick start

make setup                        # pnpm + uv workspaces, pre-commit, Playwright Chromium, .env
make city CITY=mumbai             # city-in-a-box layers (downloads on first run, then cached)
make bundle BUNDLE=MUM-2019-07-02 # replay bundle: storm designer, synthetic streams, ground truth
make bake BUNDLE=MUM-2019-07-02   # pre-compute every 5-minute cycle into data/runs/
make demo                         # API :8000 + console :3000 replaying the bundle at 30x

Until a bundle is baked, make demo prints "No bundle baked yet" and opens the console in its empty state; nothing crashes. uv run varuna <target> is the identical fallback when GNU make is missing (every target is a one-line wrapper around it).

Make targets

Variables: CITY, BUNDLE, ARGS (extra flags passed through). Targets whose engine is not built yet exit with code 2 and name the phase that delivers them.

Repository layout

varuna/
├── SPEC.md                 build spec (single source of truth)
├── Makefile                  every workflow is a make target -> uv run varuna <target>
├── apps/command/             Next.js 16 app: landing, console, public map, every screen
├── services/
│   ├── api/                  FastAPI: products, routing, alerts, replay controls, WS /v1/live
│   ├── city/                 city-in-a-box pipeline (DEM, OSM, conditioning, drain synthesis)
│   ├── replay/               bundle loader, storm designer, synthetic streams, clock
│   ├── sky/                  QPE, gauge merge, optical flow, STEPS ensemble
│   ├── twin/                 2D local-inertial solver, 1D drain solver, coupling, boundaries
│   ├── pulse/                traffic anomaly detector, report ingestion, EnKF
│   ├── flash/                reduced-order emulator (P0), GNN surrogate (P1)
│   ├── products/             segment and node forecasts, rasters, hotspots, alerts, pumps
│   ├── route/                time-dependent routing, reachability, provider feeds
│   ├── cycle/                orchestrator, in-process bus, run registry, bake
│   └── verify/               verification scores per event
├── packages/
│   ├── schemas/              Pydantic models, JSON schemas, settings, paths, tokens, ramps
│   └── tokens/               tokens.json -> CSS variables, Tailwind theme, TS and Python ramps
├── tools/varuna_cli/         the `varuna` task runner behind every make target
├── city/                     per-city static layers (gitignored; make city)
├── bundles/                  replay bundles (heavy members gitignored)
├── data/runs/                run artifacts (gitignored; make bake)
├── docs/                     blueprint, DECISIONS, SIMPLIFICATIONS, CHANGELOG, QA, API, screens
└── tests/                    cross-service tests, offline guard, Playwright e2e

The five-minute cycle

flowchart LR
    R[Radar frames<br/>gauges, tide] --> S[Sky<br/>QC, Z-R, merge, STEPS ensemble]
    S --> T[Twin<br/>2D shallow water + 1D drains]
    S --> F[Flash-lite<br/>reduced-order emulator, 50 members]
    T --> P[Pulse<br/>EnKF over blockage beta]
    F --> P
    O[Traffic speeds<br/>citizen reports] --> P
    P --> Q[Products<br/>segments, rasters, hotspots, attribution]
    Q --> C[Command<br/>alerts, pumps, console]
    Q --> RT[Route<br/>time-dependent routing, reachability]
    Q --> M[Public map<br/>and report flow]

Every stage records its milliseconds in run.json; the console's cycle budget bar and GET /v1/cycle/status show them. The API contract is in docs/API.md.

Windows notes

• Keep the repository outside OneDrive and out of paths with spaces; C:\dev\varuna is the reference location (ADR-0001 in docs/DECISIONS.md). OneDrive sync breaks .venv, node_modules and .next renames.
• GNU make comes from winget at user scope: winget install ezwinports.make. The binary lands in %LOCALAPPDATA%\Microsoft\WinGet\Packages\ezwinports.make_*\bin; add that folder to PATH or use uv run varuna <target> directly (ADR-0004).
• uv uses the Windows certificate store: [tool.uv] system-certs = true in pyproject.toml and UV_SYSTEM_CERTS=1 in .env.example (ADR-0002).
• Norton "Web/Mail Shield" re-signs TLS on the demo laptop, so Python downloads go through varuna_schemas.net (OS trust store via truststore) and GDAL only ever reads local files from city/cache/ (ADR-0006). Do not set GDAL_HTTP_UNSAFESSL.
• Prefer Git Bash for the commands above; the Makefile also works from cmd.exe and PowerShell because every recipe is a plain uv run varuna ... line.

What it measures

Every number here comes from the artifacts in this repository, not from an estimate. The ones that are bad are here anyway; docs/QA.md says why for each.

Offline

make pack              # dist/varuna-offline: runs, city layers, bundles, open-data cache

830 MB, and the finale runs from it with the venue's Wi-Fi off. The basemap imagery is not in it

• Esri's tiles are not redistributable - so with no network the map draws the city's own GIS: the 39,259 building footprints and 21,296 street segments VARUNA derived. That is what it was built to do, and the package says so when it finishes.

Checks

make test              # pnpm lint + typecheck + test + lint:design, then pytest --cov
make e2e               # Playwright: the smoke test, the demo script, and the accessibility scan
VARUNA_OFFLINE=1 uv run pytest tests   # the offline guard blocks non-loopback sockets
pre-commit run --all-files

CI (.github/workflows/ci.yml) runs the same four lanes: web, python, e2e and Lighthouse on /.

make e2e covers three things: that the shell renders, that every beat of the demo script works (tests/e2e/demo.spec.ts, one test per moment of SPEC.md 15, asserting the numbers exist rather than their values), and that thirteen screens have no WCAG 2.1 AA violations (tests/e2e/a11y.spec.ts, axe plus two keyboard tests).

Documentation

• docs/CONVENTIONS.md: real library versions and coding conventions
• docs/DECISIONS.md: architecture decision records
• docs/SIMPLIFICATIONS.md: every simplification versus the blueprint
• docs/API.md: endpoint table, error envelope, time formats
• docs/CHANGELOG.md and docs/QA.md

Built With

• css
• dockerfile
• javascript
• makefile
• python
• rust
• shell
• typescript
