Abstract

While working on the ESE Labs through the semester, we realized how inconvenient it is to hook up banana clips to a DMM or Oscilloscope every time we wanted to measure an electrical component. The Smart Bread Board(SBB) utilizes an Arduino Uno and a LCD shield to mimic the functions of a power supply, digital multimeter, function generator and oscilloscope. The power supply and DMM are implemented with simple voltage dividers and analog inputs. The function generator will be implemented using Astable Multivilbrators. Our goal is to create a multifunctional lab that engineers can with them no matter where they go.
