ScienceLoop - AI4Science Project

An AI4Science project using SpoonOS(Custom Agents, Base Tool, MCP protocol) for understanding scientific papers, generating hypotheses, creating simulation plans, generating executable code, running simulations, fixing errors, and generating comprehensive reports.

Project Structure

ScienceLoop/
├── agents/
│   ├── PaperUnderstandingAgent.py    # Step 1: Analyzes PDFs and extracts structured data
│   ├── KnowledgeGraphAgent.py         # Step 2: Builds knowledge graph from Step 1 output
│   ├── HypothesisAgent.py             # Step 3: Generates testable hypotheses
│   ├── SimulationPlanAgent.py         # Step 4: Creates simulation-ready plans
│   ├── DatasetAgent.py                # Step 5: Generates/downloads required datasets
│   ├── CodeGeneratorAgent.py         # Step 6: Generates runnable Python code
│   ├── SimulationRunnerAgent.py       # Step 7: Executes simulations and captures results
│   ├── ErrorFeedbackAgent.py          # Step 8: Analyzes errors and generates fix requests
│   └── ReportAgent.py                 # Step 9: Generates comprehensive reports
├── tools/
│   └── pdf_reader_tool.py             # SpoonOS PDF reader tool (BaseTool)
├── papers/                            # Place PDF files here
│   ├── bio paper/                    # Example: Biology paper with all outputs
│   ├── sna paper/                    # Example: Network science paper with all outputs
│   ├── physics paper/                # Example: Physics paper with all outputs
│   ├── mldl/                         # Example: ML/DL paper with all outputs
│   └── saish/                        # Example: Classification paper with all outputs
├── results/                           # Simulation run results (auto-generated)
│   └── {run_id}/
│       ├── logs/
│       │   ├── stdout.txt
│       │   └── stderr.txt
│       ├── artifacts/                 # Generated plots, CSV files, etc.
│       ├── error_report.json          # (or simulation_result.json)
│       └── fix_request.json           # (if error fixing was performed)
├── spoon.json                        # SpoonOS configuration
├── requirements.txt                  # Python dependencies
├── AGENT_INPUTS.md                   # Complete agent inputs reference
└── README.md                         # This file

Setup

  1. Create and activate virtual environment: ```bash # macOS/Linux python3 -m venv spoon-env source spoon-env/bin/activate

Windows (PowerShell)

python -m venv spoon-env .\spoon-env\Scripts\Activate.ps1


2. **Install dependencies:**
```bash
pip install -r requirements.txt
  1. Configure API keys in .env file:

Create a .env file in the project root:

# OpenAI API Configuration
OPENAI_API_KEY=your-openai-api-key-here
OPENAI_MODEL=gpt-4-turbo

# Anthropic/Claude API Configuration
ANTHROPIC_API_KEY=your-anthropic-api-key-here
ANTHROPIC_MODEL=claude-sonnet-4-5-20250929

Model Configuration:

  • PaperUnderstandingAgent: Uses gpt-4-turbo (via OPENAI_MODEL)
  • KnowledgeGraphAgent: Uses gpt-4-turbo (via OPENAI_MODEL)
  • HypothesisAgent: Uses claude-sonnet-4-5-20250929 (via ANTHROPIC_MODEL)
  • SimulationPlanAgent: Uses claude-sonnet-4-5-20250929 (via ANTHROPIC_MODEL)
  • CodeGeneratorAgent: Uses gpt-4o (via OPENAI_MODEL, best for code generation)
  • DatasetAgent: Uses claude-sonnet-4-5-20250929 (via ANTHROPIC_MODEL)
  • SimulationRunnerAgent: Pure Python (no LLM)
  • ErrorFeedbackAgent: Uses gpt-4o (via OPENAI_MODEL)
  • ReportAgent: Uses claude-sonnet-4-5-20250929 (via ANTHROPIC_MODEL)
  1. Place your PDF files in the papers/ directory.

Complete Pipeline Overview

The ScienceLoop pipeline consists of 9 agents working in sequence:

Phase 1: Paper Analysis (Steps 1-4)

  1. PaperUnderstandingAgent: Extracts formulas, variables, relationships, and key ideas from PDFs
  2. KnowledgeGraphAgent: Creates a scientific knowledge graph with nodes and edges
  3. HypothesisAgent: Generates testable scientific hypotheses
  4. SimulationPlanAgent: Creates precise, executable simulation plans

Phase 2: Code & Data Preparation (Steps 5-6)

  1. DatasetAgent: Automatically generates/downloads required datasets
  2. CodeGeneratorAgent: Converts simulation plans into runnable Python scripts

Phase 3: Simulation Execution (Step 7)

  1. SimulationRunnerAgent: Executes simulation scripts, captures outputs, stores artifacts

Phase 4: Error Fixing (Step 8 - Manual Loop)

  1. ErrorFeedbackAgent: Analyzes errors and generates fix requests for code regeneration

Phase 5: Report Generation (Step 9)

  1. ReportAgent: Generates comprehensive reports comparing expected vs actual outcomes

Complete Pipeline Flow

PDF
  ↓
PaperUnderstandingAgent → understand.json
  ↓
KnowledgeGraphAgent → knowledge_graph.json
  ↓
HypothesisAgent → hypothesis.json
  ↓
SimulationPlanAgent → simulation_plan.json
  ↓                    ↓
DatasetAgent      CodeGeneratorAgent
  ↓                    ↓
datasets_manifest.json  simulation.py
  ↓                    ↓
SimulationRunnerAgent → error_report.json / simulation_result.json
  ↓ (if error)
ErrorFeedbackAgent → fix_request.json → CodeGeneratorAgent (regenerate)
  ↓ (repeat until success)
ReportAgent → report.json, report.md

Usage

Important: Make sure the virtual environment is activated before running:

source spoon-env/bin/activate  # macOS/Linux
# or
.\spoon-env\Scripts\Activate.ps1  # Windows PowerShell

Complete Pipeline Example

For a paper in papers/saish/:

Phase 1: Paper Analysis

# Step 1: Paper Understanding
python agents/PaperUnderstandingAgent.py --pdf "papers/saish/saish paper.pdf"
# Output: papers/saish/understand.json

# Step 2: Knowledge Graph
python agents/KnowledgeGraphAgent.py --input "papers/saish/understand.json"
# Output: papers/saish/knowledge_graph.json

# Step 3: Hypothesis Generation
python agents/HypothesisAgent.py --input "papers/saish/understand.json" --kg "papers/saish/knowledge_graph.json"
# Output: papers/saish/hypothesis.json

# Step 4: Simulation Plan
python agents/SimulationPlanAgent.py --hypothesis "papers/saish/hypothesis.json" --paper "papers/saish/understand.json" --kg "papers/saish/knowledge_graph.json"
# Output: papers/saish/simulation_plan.json

Phase 2: Code & Data Preparation

# Step 5: Dataset Generation
python agents/DatasetAgent.py --plan "papers/saish/simulation_plan.json"
# Output: papers/saish/datasets_manifest.json + datasets/

# Step 6: Code Generation (with datasets)
python agents/CodeGeneratorAgent.py --plan "papers/saish/simulation_plan.json" --datasets "papers/saish/datasets_manifest.json"
# Output: papers/saish/simulation.py

Phase 3: Simulation Execution

# Step 7: Run Simulation
python agents/SimulationRunnerAgent.py \
  --python-file "papers/saish/simulation.py" \
  --datasets "papers/saish/datasets_manifest.json" \
  --simulation-plan "papers/saish/simulation_plan.json" \
  --timeout 600
# Output: results/{run_id}/error_report.json or simulation_result.json

Phase 4: Error Fixing Loop (Manual - Repeat Until Success)

If the simulation has errors, fix them manually:

# Get latest error report
LATEST_RESULT=$(ls -td results/*/error_report.json 2>/dev/null | head -1)
echo "Error report: $LATEST_RESULT"

# Generate fix request
python agents/ErrorFeedbackAgent.py \
  --error-report "$LATEST_RESULT" \
  --simulation-plan "papers/saish/simulation_plan.json" \
  --original-code "papers/saish/simulation.py" \
  --output "$(dirname $LATEST_RESULT)/fix_request.json"

# Regenerate code with fixes
TEMP_PLAN=$(python3 -c "
import json
import tempfile
f = open('$(dirname $LATEST_RESULT)/fix_request.json')
d = json.load(f)
p = d['simulation_plan'].copy()
p.update({
    '_fix_instructions': d['fix_instructions'],
    '_error_context': d['error_context'],
    '_error_summary': d['error_summary'],
    '_explanation': d['explanation']
})
t = tempfile.NamedTemporaryFile(mode='w', suffix='.json', delete=False)
json.dump(p, t, indent=2)
t.close()
print(t.name)
")
python agents/CodeGeneratorAgent.py --plan "$TEMP_PLAN" --datasets "papers/saish/datasets_manifest.json"
rm "$TEMP_PLAN"

# Re-run simulation (repeat Step 7)
python agents/SimulationRunnerAgent.py \
  --python-file "papers/saish/simulation.py" \
  --datasets "papers/saish/datasets_manifest.json" \
  --simulation-plan "papers/saish/simulation_plan.json" \
  --timeout 600

Repeat Phase 4 until simulation succeeds (status: "success")

Phase 5: Report Generation (Only After Success)

# Step 9: Generate Report
LATEST_RESULT=$(ls -td results/*/simulation_result.json 2>/dev/null | head -1)
python agents/ReportAgent.py \
  --paper-understanding "papers/saish/understand.json" \
  --knowledge-graph "papers/saish/knowledge_graph.json" \
  --hypothesis "papers/saish/hypothesis.json" \
  --simulation-plan "papers/saish/simulation_plan.json" \
  --simulation-result "$LATEST_RESULT" \
  --output "papers/saish/report.json" \
  --markdown-output "papers/saish/report.md"
# Output: papers/saish/report.json, papers/saish/report.md

Agent Inputs Reference

Quick Reference Table

Agent Required Inputs Optional Inputs
PaperUnderstandingAgent --pdf None
KnowledgeGraphAgent None (uses --input or stdin) --input
HypothesisAgent --input, --kg None
SimulationPlanAgent --hypothesis, --paper, --kg None
DatasetAgent --plan None
CodeGeneratorAgent --plan --datasets
SimulationRunnerAgent --python-file --datasets, --workdir, --timeout, --auto-fix, --simulation-plan
ErrorFeedbackAgent --error-report, --simulation-plan --original-code, --output
ReportAgent --paper-understanding, --knowledge-graph, --hypothesis, --simulation-plan, --simulation-result --error-history, --output, --markdown-output

Detailed Agent Specifications

1. PaperUnderstandingAgent

  • Input: --pdf (string): Path to PDF file
  • Output: understand.json (saved in PDF's directory)
  • Model: GPT-4 Turbo
  • Purpose: Extracts structured information from scientific PDFs

2. KnowledgeGraphAgent

  • Input: --input (string, optional): Path to understand.json (or reads from stdin)
  • Output: knowledge_graph.json (saved in same directory)
  • Model: GPT-4 Turbo
  • Purpose: Builds scientific knowledge graph

3. HypothesisAgent

  • Input:
    • --input (string): Path to understand.json
    • --kg (string): Path to knowledge_graph.json
  • Output: hypothesis.json (saved in same directory)
  • Model: Claude 4.5 Sonnet
  • Purpose: Generates testable scientific hypotheses

4. SimulationPlanAgent

  • Input:
    • --hypothesis (string): Path to hypothesis.json
    • --paper (string): Path to understand.json
    • --kg (string): Path to knowledge_graph.json
  • Output: simulation_plan.json (saved in same directory)
  • Model: Claude 4.5 Sonnet
  • Purpose: Creates executable simulation plans

5. DatasetAgent

  • Input: --plan (string): Path to simulation_plan.json
  • Output:
    • datasets_manifest.json (saved in same directory)
    • Dataset files in datasets/ subdirectory
  • Model: Claude 4.5 Sonnet
  • Purpose: Generates/downloads required datasets

6. CodeGeneratorAgent

  • Input:
    • --plan (string): Path to simulation_plan.json
    • --datasets (string, optional): Path to datasets_manifest.json (recommended)
  • Output: simulation.py (saved in same directory)
  • Model: GPT-4o
  • Purpose: Generates runnable Python simulation code
  • Features:
    • Intelligently infers required libraries
    • Generates complete, standalone scripts
    • Handles error fix instructions from ErrorFeedbackAgent
    • Converts dataset paths to be relative to script directory
    • Validates code before returning

7. SimulationRunnerAgent

  • Input:
    • --python-file (string): Path to simulation.py
    • --datasets (string, optional): Path to datasets_manifest.json
    • --workdir (string, optional): Working directory (default: parent of python-file)
    • --timeout (number, optional): Timeout in seconds (default: 600)
    • --auto-fix (boolean, optional): Auto-fix errors (requires --simulation-plan)
    • --simulation-plan (string, optional): Required if --auto-fix is used
  • Output:
    • results/{run_id}/error_report.json (on error) or simulation_result.json (on success)
    • results/{run_id}/logs/stdout.txt
    • results/{run_id}/logs/stderr.txt
    • results/{run_id}/artifacts/* (plots, CSV files, etc.)
  • Model: Pure Python (no LLM)
  • Purpose: Executes simulations and captures all outputs

8. ErrorFeedbackAgent

  • Input:
    • --error-report (string): Path to error_report.json from SimulationRunnerAgent
    • --simulation-plan (string): Path to simulation_plan.json
    • --original-code (string, optional): Path to simulation.py
    • --output (string, optional): Path to save fix_request.json
  • Output: fix_request.json (saved to specified path or printed to stdout)
  • Model: GPT-4o
  • Purpose: Analyzes errors and generates structured fix requests
  • Features:
    • Detects specific error types (FileNotFoundError, ValueError, dimension mismatches)
    • Provides actionable fix instructions
    • Includes error context and explanation

9. ReportAgent

  • Input:
    • --paper-understanding (string): Path to understand.json
    • --knowledge-graph (string): Path to knowledge_graph.json
    • --hypothesis (string): Path to hypothesis.json
    • --simulation-plan (string): Path to simulation_plan.json
    • --simulation-result (string): Path to error_report.json or simulation_result.json
    • --error-history (string, optional): Path to JSON list of error reports
    • --output (string, optional): Path to save report.json
    • --markdown-output (string, optional): Path to save report.md
  • Output:
    • report.json (machine-readable summary)
    • report.md (human-readable report)
  • Model: Claude 4.5 Sonnet
  • Purpose: Generates comprehensive analysis reports
  • Note: Only run after simulation succeeds (status: "success")

Output Files

All outputs are dynamically saved in the same directory as the input PDF:

papers/your-paper/
├── paper.pdf                    # Original PDF
├── understand.json              # Step 1: Paper understanding
├── knowledge_graph.json         # Step 2: Knowledge graph
├── hypothesis.json              # Step 3: Hypothesis
├── simulation_plan.json         # Step 4: Simulation plan
├── datasets_manifest.json       # Step 5: Dataset manifest
├── datasets/                    # Step 5: Generated datasets
│   ├── synthetic/
│   │   └── classification_data.csv
│   └── ...
├── simulation.py               # Step 6: Generated Python code
└── report.json                 # Step 9: Report (JSON)
└── report.md                   # Step 9: Report (Markdown)

results/{run_id}/
├── logs/
│   ├── stdout.txt
│   └── stderr.txt
├── artifacts/                  # Generated plots, CSV files, etc.
│   ├── plot1.png
│   └── ...
├── error_report.json           # (on error) or simulation_result.json (on success)
└── fix_request.json            # (if error fixing was performed)

Output Formats

understand.json

{
  "summary": "Brief scientific summary",
  "formulas": ["formula 1", "formula 2"],
  "relationships": ["relationship 1", "relationship 2"],
  "variables": ["variable 1: description", "variable 2: description"],
  "key_ideas": ["idea 1", "idea 2"]
}

knowledge_graph.json

{
  "nodes": ["entity1", "entity2", "entity3"],
  "edges": [
    {
      "source": "entity1",
      "relation": "relationship description",
      "target": "entity2"
    }
  ]
}

hypothesis.json

{
  "hypothesis": "A clear, testable scientific hypothesis statement",
  "justification": "Explanation of why this hypothesis follows logically from the paper"
}

simulation_plan.json

{
  "simulation_equations": ["equation1", "equation2"],
  "constants_required": [
    {
      "name": "constant_name",
      "description": "what it represents",
      "value_or_range": "value or range"
    }
  ],
  "variables_to_vary": [
    {
      "name": "variable_name",
      "description": "what it represents",
      "range": "[min, max]",
      "units": "if applicable"
    }
  ],
  "procedure_steps": ["Step 1: ...", "Step 2: ..."],
  "expected_outcomes": "Description of expected patterns"
}

datasets_manifest.json

{
  "dataset_type": "graph",
  "datasets": {
    "barabasi_albert": "path/to/barabasi_albert_n100_m3.edgelist",
    "watts_strogatz": "path/to/watts_strogatz_n100_k6_p0.30.edgelist"
  },
  "reasoning": "Explanation of dataset requirements"
}

error_report.json / simulation_result.json

{
  "status": "error" | "success",
  "run_id": "<uuid>",
  "stdout": "<full text log>",
  "stderr": "<full text log or empty>",
  "exit_code": <int>,
  "artifacts": [
    {
      "filename": "plot1.png",
      "path": "results/<run_id>/artifacts/plot1.png"
    }
  ],
  "results_path": "results/<run_id>",
  "error_summary": "<if error>" (optional)
}

fix_request.json

{
  "needs_regeneration": true,
  "error_context": "<exact traceback>",
  "explanation": "<why the error occurred>",
  "fix_instructions": [
    "Correct variable X",
    "Import Y library",
    "Adjust dataset path to Z"
  ],
  "simulation_plan": { ... }
}

report.json

{
  "success": true | false | "partial",
  "reason": "<one-paragraph explanation>",
  "matched_expectations": [
    "<which parts of expected_outcomes were clearly observed>"
  ],
  "unmet_expectations": [
    "<which expected behaviors were not clearly observed or contradicted>"
  ],
  "key_observations": [
    "<short bullet strings for main findings>"
  ],
  "recommendations": [
    "<concrete next actions for future runs or code changes>"
  ]
}

Example Workflows

Complete Pipeline for Biology Paper

# Phase 1: Analysis
python agents/PaperUnderstandingAgent.py --pdf "papers/bio paper/scalley97A.pdf"
python agents/KnowledgeGraphAgent.py --input "papers/bio paper/understand.json"
python agents/HypothesisAgent.py --input "papers/bio paper/understand.json" --kg "papers/bio paper/knowledge_graph.json"
python agents/SimulationPlanAgent.py --hypothesis "papers/bio paper/hypothesis.json" --paper "papers/bio paper/understand.json" --kg "papers/bio paper/knowledge_graph.json"

# Phase 2: Preparation
python agents/DatasetAgent.py --plan "papers/bio paper/simulation_plan.json"
python agents/CodeGeneratorAgent.py --plan "papers/bio paper/simulation_plan.json" --datasets "papers/bio paper/datasets_manifest.json"

# Phase 3: Execution
python agents/SimulationRunnerAgent.py --python-file "papers/bio paper/simulation.py" --datasets "papers/bio paper/datasets_manifest.json" --simulation-plan "papers/bio paper/simulation_plan.json"

# Phase 4: Error Fixing (if needed - repeat until success)
# ... (see manual error fixing loop above)

# Phase 5: Report (only after success)
LATEST_RESULT=$(ls -td results/*/simulation_result.json 2>/dev/null | head -1)
python agents/ReportAgent.py --paper-understanding "papers/bio paper/understand.json" --knowledge-graph "papers/bio paper/knowledge_graph.json" --hypothesis "papers/bio paper/hypothesis.json" --simulation-plan "papers/bio paper/simulation_plan.json" --simulation-result "$LATEST_RESULT" --output "papers/bio paper/report.json" --markdown-output "papers/bio paper/report.md"

Error Handling

Manual Error Fixing Loop

When SimulationRunnerAgent reports an error:

  1. Get the latest error report:

    LATEST_RESULT=$(ls -td results/*/error_report.json 2>/dev/null | head -1)

  2. Generate fix request:

    python agents/ErrorFeedbackAgent.py \
 --error-report "$LATEST_RESULT" \
 --simulation-plan "papers/your-paper/simulation_plan.json" \
 --original-code "papers/your-paper/simulation.py" \
 --output "$(dirname $LATEST_RESULT)/fix_request.json"

  3. Regenerate code with fixes:

    TEMP_PLAN=$(python3 -c "
import json
import tempfile
f = open('$(dirname $LATEST_RESULT)/fix_request.json')
d = json.load(f)
p = d['simulation_plan'].copy()
p.update({
   '_fix_instructions': d['fix_instructions'],
   '_error_context': d['error_context'],
   '_error_summary': d['error_summary'],
   '_explanation': d['explanation']
})
t = tempfile.NamedTemporaryFile(mode='w', suffix='.json', delete=False)
json.dump(p, t, indent=2)
t.close()
print(t.name)
")
python agents/CodeGeneratorAgent.py --plan "$TEMP_PLAN" --datasets "papers/your-paper/datasets_manifest.json"
rm "$TEMP_PLAN"

  4. Re-run simulation:

    python agents/SimulationRunnerAgent.py \
 --python-file "papers/your-paper/simulation.py" \
 --datasets "papers/your-paper/datasets_manifest.json" \
 --simulation-plan "papers/your-paper/simulation_plan.json"

  5. Repeat steps 1-4 until status is "success"

Common Errors & Solutions

  1. FileNotFoundError: [Errno 2] No such file or directory: 'papers/.../datasets/...'

    • Solution: CodeGeneratorAgent now converts dataset paths to be relative to the script's directory. Ensure --datasets argument is provided.

  2. ValueError: x and y must have same first dimension

    • Solution: ErrorFeedbackAgent detects this and provides specific fix instructions. Regenerate code with the fix request.

  3. ModuleNotFoundError: No module named 'X'

    • Solution: Install missing dependencies: pip install -r requirements.txt

  4. Simulation hangs or times out

    • Solution: Increase --timeout value or optimize simulation code (reduce parameter ranges, add progress output)

  5. Report generation fails

    • Solution: Ensure simulation completed successfully first (status: "success" in simulation_result.json)

Dependencies

See requirements.txt for full list. Key dependencies:

  • spoon-ai-sdk>=0.3.0 - SpoonOS core framework
  • spoon-toolkits>=0.2.0 - Extended toolkits
  • pypdf>=3.0.0 - PDF reading
  • openai>=1.0.0 - OpenAI API client
  • anthropic>=0.34.0 - Anthropic/Claude API client
  • networkx>=3.0 - Graph generation
  • numpy>=1.24.0 - Numerical computations
  • scipy>=1.10.0 - Scientific computing
  • matplotlib>=3.7.0 - Plotting
  • scikit-learn>=1.3.0 - Machine learning
  • pandas - Data manipulation
  • requests>=2.31.0 - HTTP requests
  • python-dotenv>=1.0.0 - Environment variable management

Key Features

  • Dynamic File Saving: All outputs are saved in the same directory as the input PDF
  • Domain Agnostic: Works for biology, chemistry, physics, computer science, ML, algorithms, systems, etc.
  • Model Selection: Uses GPT-4 Turbo for understanding/graphs, Claude 4.5 Sonnet for reasoning/planning, GPT-4o for code generation
  • Error Handling: Robust error detection, analysis, and automated code regeneration
  • Code Validation: Pre-generation validation to catch common errors before runtime
  • Intelligent Plotting: CodeGeneratorAgent intelligently decides when to generate plots based on simulation plan
  • Comprehensive Reports: Detailed analysis comparing expected vs actual outcomes

Notes

  • Context Windows: Agents handle large PDFs with truncation and model fallbacks
  • Error Recovery: Manual error-fixing loop ensures robust code generation
  • Path Handling: All dataset paths are automatically converted to be relative to script execution directory
  • Plot Saving: Generated code uses plt.savefig() and plt.close() instead of plt.show() to prevent blocking
  • Non-Interactive Backend: Matplotlib uses 'Agg' backend for non-interactive plotting

Additional Resources

  • AGENT_INPUTS.md: Complete reference for all agent inputs and usage
  • RUN_SAISH_PAPER.md: Step-by-step guide for running complete pipeline
  • MANUAL_ERROR_FIX.md: Detailed error fixing instructions

License

MIT License

Built With

  • spoonos
  • trae
Share this project:

Updates
