invoicescan-ai

Using live agent to help user scan invoice, unknown fields are trained on the spot by gemini. these are used for uptraining in document ai. scanned items are all stored on googlesheet

Comment

Inspiration My family runs a small business. Every month, we process stacks of invoices — suppliers from different countries, different tax regimes, different currencies. Is the GST right on this Singapore invoice? Did the rate change? Is this a duplicate? Is this vendor's bank account the same as last time?

Existing tools either extract data without verifying it (OCR apps), or verify tax rules without a human-friendly interface (enterprise platforms at $500+/month). None let you just point your phone at an invoice and ask "is this right?"

I wanted something simple: snap a photo, hear the answer, move on to the next invoice. The AI handles the rest — tax verification, fraud detection, logging — all in the background. And if it misses a field I care about, I teach it once and it remembers forever. This is just the training process for future uptraining on document ai.

What it does InvoiceScan AI is a voice-powered invoice scanning agent that works on any phone or desktop. You scan invoices with your camera or upload files, and have a real-time voice conversation with an AI that:

Reads instantly — Gemini Live sees the invoice and speaks the vendor and total within a second, before Document AI even finishes Extracts accurately — Document AI pulls 46 structured fields with confidence scores (Layer 1: grounded) Knows the country — Auto-detects which of 57 tax regimes applies from tax IDs, currency, and field patterns Verifies the math — Background: checks tax against the correct rate for that country AND that date (historical rate awareness — Singapore was 8% in 2023, 9% in 2024) Catches fraud — 7 automated checks: duplicates, bank changes, suspicious amounts, weekend dates, sequence gaps Logs everything — Google Sheets with dynamic columns that auto-create as new field types appear Learns your needs — Create extraction recipes via voice ("always extract PO numbers"). Recipes auto-run on future invoices Shares knowledge — Subscribe to community recipes from Firestore. What works for one user helps everyone How we built it Direct Gemini Live — No Proxy The browser connects directly to Gemini Live API via WebSocket. Audio and images go straight from phone to Gemini — no server in the middle. This gives us sub-second voice latency. The server only handles REST: uploads, Document AI, Sheets, tool dispatch.

Phone ──WebSocket──► Gemini Live API (voice + vision, direct) │ │ │ tool call ──► Server ──► Firestore │ └──── upload ────► Server ──► Document AI ──► Sheets │ [background] tax verify + fraud + recipes │ Analysis column in Sheets 1 Tool, Everything Else Automatic We optimized from 14 tools down to 1 tool on the Gemini Live agent: manage_recipes. Everything else runs automatically on upload — no agent intervention needed.

Automatic pipeline (on every upload):

Document AI extraction (46 fields) Tax regime detection (57 countries) Fraud detection (7 checks) Google Sheets logging Vertex AI Search indexing Background post-processing:

Tax math verification against historical rates Low-confidence field escalation to Gemini Vision Compliance validation Auto-run matching user recipes from Firestore This means the agent can focus on conversation — it doesn't waste turns on infrastructure. When the user asks "is the tax right?", the answer is already in the Analysis column.

Three-Layer Extraction Layer Engine What When 1 Document AI 46 standard fields, bounding boxes, confidence scores Every upload 2 Gemini Vision 228+ custom fields across 16 industry presets Via recipes 3 Community Recipes User-created extraction prompts, shared via Firestore Auto-matched Firestore Recipe System Recipes are the learning mechanism. When the default extraction misses something:

User says "extract the PO number" via voice Agent creates a recipe (Gemini Vision prompt) and saves to Firestore Tests it against the current invoice — user confirms it works Recipe auto-runs on all future matching invoices Other users can discover and subscribe to the recipe Each user has their own subscription list (users/{user_id}/recipe_ids). Recipes track usage stats — score rises with successful extractions, falls on failures.

Tech Stack AI: Gemini 2.5 Flash Live (native audio + vision, direct browser WebSocket) Extraction: Google Document AI Invoice Parser Custom Fields: Gemini Vision (structured JSON, 16 industry presets) Recipes: Cloud Firestore (per-user subscriptions, community sharing) Search: Vertex AI Search (semantic search over past invoices) Logging: Google Sheets API (3 dynamic sheets + Analysis column) Backend: FastAPI on Cloud Run Frontend: Mobile-first HTML/CSS/JS (camera, mic, thumbnail queue, history view) Challenges we ran into 14 tools was too many. Gemini Live wasted turns calling tools that already ran automatically (parse_invoice on data that was already parsed). We iterated down to 1 tool by moving everything to the server pipeline and background processing. Less is more.

Tax complexity is insane. India has compound taxes (cess on top of CGST+SGST). Brazil has 5 overlapping taxes. US has state+county+city. Hotels can have 20+ line items with different rates. We built a detection engine with 57 regimes and historical rate tracking.

Historical rates matter. A 2023 Singapore invoice at 8% GST is correct — the rate changed to 9% in January 2024. Our engine checks the invoice DATE, not today's rate. We track rate change history for every regime.

Recipes replaced three systems. We originally had separate systems for field learning, local recipes, and community recipes. After iteration, we realized they all do the same thing: store a prompt, run it on matching invoices. One Firestore collection with user subscriptions replaced all three.

API key in client-side JS. The browser connects directly to Gemini — it needs the API key. We solved this with a /api/config endpoint that serves the key from an environment variable. Never in code, never in git history.

Accomplishments that we're proud of 57 countries with tax regime detection, historical rate verification, and compliance checking 1 tool on the voice agent — everything else is automatic. Clean, fast, no wasted turns Sub-second voice response via direct browser-to-Gemini WebSocket (no server proxy for audio) Recipe system where users teach the AI via voice and it remembers forever (Firestore-persistent) Community sharing — one user's recipe benefits everyone who subscribes 7 fraud checks running automatically on every upload Dynamic Google Sheets that handle any invoice format without schema changes History view with Document AI bounding box overlays — tap any field to highlight it on the invoice image What we learned Fewer tools = better agent. Going from 14 to 1 tool made the agent faster, more accurate, and more conversational. The agent should talk, not orchestrate infrastructure. Automate everything you can. If the server can do it on upload, don't make the agent call a tool for it. Tax verification, fraud detection, compliance — all background tasks now. Recipes > field learning. A recipe is just a prompt with triggers. It subsumes field learning, custom extraction, and community sharing into one concept. Users understand "recipe" intuitively. Direct WebSocket matters. Proxying audio through our server added 200-400ms latency. Direct browser-to-Gemini eliminated it. The voice experience went from "okay" to "wow." Global tax is an opportunity. The harder the invoice, the more value the AI adds. A US sales tax invoice is easy. A Brazilian nota fiscal with ICMS + IPI + PIS + COFINS is where the agent really shines. What's next for InvoiceScan AI Accounting integrations — QuickBooks, Xero, FreshBooks via MCP servers for automatic bookkeeping Multi-invoice analysis — "How much did I spend on office supplies this quarter?" across all scanned invoices E-invoicing validation — verify against Peppol, ZATCA, CFDI, FatturaPA standards Recipe marketplace — browse and subscribe to popular recipes by country/industry Offline scanning — PWA with camera capture, sync recipes and results when connected Built With gemini-live-api gemini-2.5-flash google-document-ai google-cloud-firestore vertex-ai-search google-cloud-run google-sheets-api fastapi python javascript GCP Services Used Service Purpose Gemini 2.5 Flash (Live API) Voice + vision agent (direct browser WebSocket) Document AI Invoice Parser — 46 field extraction with bounding boxes Cloud Firestore Recipe storage + user subscriptions Vertex AI Search Semantic search over past invoices Google Sheets API Auto-log invoices (3 dynamic sheets) Cloud Run Serverless deployment
