ScanE

Tagline: Capture coach for equipment photos — usable, retake, or needs review.

An AI camera assistant that helps someone photograph electronic equipment correctly. Take or upload front, rear / ports, and label photos; ScanE checks whether each shot is usable, needs a retake, or needs a person to look, then tells you what to fix.

Built for the American Circular Capture Coach track at Bay Hacks: evaluate device photos for blur, lighting, framing, obstructed labels, and missing required views, and give immediate retake instructions.

Devpost gallery: attach a 2–3 minute demo video plus screenshots of Camera, Storage, Analysis (roller + Problem / Solution), and the web dashboard. Live prototype: phone in Expo Go + http://127.0.0.1:8000/dashboard/ on the API host.

Inspiration

Circular-economy shops photograph scrap electronics so someone later can identify the chassis, see the ports, and read the label — an asset tag, spec plate, sticker, or any other marking on the device. A blurry label or a cropped rear panel wastes a trip. The Capture Coach challenge asked for a prototype that coaches that capture in the moment, without claiming to identify a device, read serials, or certify erasure.

ScanE is that coach: a phone camera for the bench, a web dashboard for review, and a shared library so the same account can shoot on a phone and inspect on a laptop.

What it does

An operator captures or uploads photos of a device. ScanE:

Names each photo as front, rear_ports, or label (Gemini by default). label is any identification label in the photo (nameplate, serial/asset sticker, barcode plate, DEMO tape, or similar), not only DEMO tape. Client view chips are hints, not labels.
Groups shots into device sets (one chassis per set) and checks the required-view checklist.
Scores capture quality locally: blur, underexposure, glare / overexposure, framing, and whether the label is covered or unreadable.
Returns Usable, Retake, or Needs review, plus a Problem and a Solution in plain language.

The label view is any equipment label meant to be read — asset tag, spec plate, sticker, or other marking — not a specific tape color or DEMO sticker.

A missing view is a set-level finding. A bad photo of a view that is present is a retake, not “missing.” Dark table backgrounds and black privacy boxes are not defects.

Status	Meaning
Usable	Adequate for the intended view
Retake	A clear failure (blur, dark, glare, cut-off frame, covered or unreadable label, …)
Needs review	The model cannot decide (uncertain view, unclear rear ports, ambiguous brightness)

Use cases

Bench capture. Photograph a device on the phone (shutter stays on Camera). Analyze the current session, or group shots in Storage first.
Desk review. Sign in at http://127.0.0.1:8000/dashboard/ with the same username as the phone Profile, upload files, and inspect the shared library. The dashboard has no camera. Photos already synced as alejj12 (20) or alejj1216 (25) appear only under that username.
Set completeness. Create Set 1, Set 2, … so each chassis has its own front / rear / label checklist. Unassigned photos are stored but not analyzed from Storage.
Retake coaching. After analysis, swipe the photo roller. Each shot shows view, status, and Problem / Solution copy such as “add light” vs “change angle.”
Practice-set checks. With the Capture Coach student package, the server can still score the published photo sets (/sets, /analyze/set) the way the challenge described.

How we built it

flowchart LR
  phone[Expo Go phone]
  dash[Web dashboard]
  api[FastAPI :8000]
  quality[OpenCV + sklearn quality]
  gemini[Gemini view naming]
  lib[Shared account library]

  phone -->|capture / upload| api
  dash -->|upload| api
  phone <-->|sign-in snapshot| lib
  dash <-->|sign-in snapshot| lib
  api --> quality
  api --> gemini
  quality -->|usable / retake / review| phone
  quality -->|usable / retake / review| dash

Layer	Stack	Role
Phone	Expo SDK 57, React Native 0.86, React 19, Expo Go	Camera, Storage, Analysis roller, Profile. Stay in Expo Go.
Dashboard	Static HTML / JS / CSS, Shoelace 2 (CDN)	Upload-only Storage + Analysis, served at `/dashboard/`
API	FastAPI, Uvicorn, port 8000	Analyze, accounts, shared library, dashboard files
View naming	Google Gemini (`gemini-3.1-flash-lite`)	Names front / rear / label and groups unknown chassis. Examples only, not an allowlist.
Quality	OpenCV + scikit-learn logistic models (`models/blur_exposure.joblib`)	Blur, exposure, glare, framing, label obstruction. Runs on the API host.
Guidance	`models/guidance.json` from practice labels	Problem / Solution sentences, not free-form LLM copy
Sync	`POST /account/login`, `GET`/`PUT /account/snapshot`, `GET /account/photos/{id}`	Same username on phone and web. After a snapshot pull, the dashboard loads each photo as a JPEG (`Content-Disposition: inline`) and shows a blob URL.

Where AI contributes. Gemini names the view and (when the client did not send a set id) groups photos by chassis. Local measurements decide usable / retake / needs_review. ScanE does not OCR the label, recover privacy boxes, identify a brand, or certify data erasure. It checks that a label photo is complete and readable enough to use.

Network and cost. Analyze posts JSON (base64 JPEGs, max side 960) to /analyze/payload. Gemini receives those working copies for unknown photos; known practice images match by hash / filename / fingerprint and skip the API call. Originals stay on the phone or in the account library. A Google AI API key is required when ANALYZE_BACKEND=gemini (the default). Flash-Lite is a low-cost hosted model; there is no silent fallback to the local view forest if the key is missing.

Phone and dashboard share one theme (mobile/src/theme.js). Analysis is a center-anchored photo roller on both; the phone holds for one second to open Storage, the dashboard hold opens the in-page grid.

Challenges we ran into

Missing is not a retake. A blurry front photo still counts as a front. The checklist is per device set, and a present-but-bad view must not be reported as absent. That split is easy to get wrong in a UI that also groups chassis.

Do not trust the chip. Operators tap Front / Rear / Label as a hint. Practice checks deliberately send the wrong chip and a generic filename. The server has to name the real view, or the guidance is attached to the wrong photo.

Campus Wi-Fi vs a laptop API. Eduroam can block phone-to-PC LAN. Health probes that hang never reach Gemini and leave Analysis stuck on Analysis in Progress. The phone tries LAN Metro, then the current Expo host, then the Expo tunnel, and treats an HTTP status (including 502) as “this Metro is alive” so a down Uvicorn is a 502, not a freeze. A 503 from analyze means view naming failed on that live server; hopping origins would hide the real error.

Gemini 3 thinks out loud. The model can return a thought object before the photos[] JSON. The server skips objects that lack photos[], ignores thought parts, sets thinking to minimal, and retries the call once.

Show the original, score a copy. Challenge rules forbid passing an enhanced image off as the capture. Previews stay the stored originals. Only the upload copy is resized (max side 960, JPEG ~0.75) for analyze.

Two clients, one library. Phone document storage and the web dashboard both read and write assigned and unassigned photos. Unassigned shots are never analyzed from Storage, except a one-photo camera session. Sync runs after sign-in, analyze, and grouping or delete, and only when a session token exists. A dashboard GET /account/snapshot 401 signs the page out; it must not leave an empty Storage grid that says “All photos are in a set.”

Accomplishments that we're proud of

A live camera flow (optional in the track) plus an upload dashboard, so a bench phone and a review laptop share one account.
Hybrid AI that matches the judging brief: local quality models and PHOTO_GUIDE rules decide status; Gemini only names views on unknown photos.
On the 34 practice images, issue codes, statuses, and phone-style view labels match the published answers, while a full set can still contain retakes.
Operator-facing Problem and Solution copy instead of raw issue codes — including two lighting codes so the instruction can say “add light” or “change angle.”
Analysis that does not blank the screen: photos stay up, cached shots show their last status immediately, and a failed call keeps the roller.
Unchanged shots reuse the last analyze rows on the phone so a second pass does not re-upload the whole set.

What we learned

Useful capture coaching is mostly rules plus measurements, with a vision model only where a chip or filename cannot be trusted. Spending more on a larger model would not have scored the blur and glare gates better; those are OpenCV features and logistic models trained on the practice labels.

Expo Go on a campus network taught us that “the API is on localhost” is not a product. Probes need timeouts, 502 from Metro means Uvicorn is down, and the tunnel has to stay in the path.

We also learned to leave uncertain as needs-review instead of filling a checklist slot with a guess. A wrong view in the green list is worse than an empty one.

What's next for ScanE

More labeled extra views (data/extra_views/) for tougher devices, a fully local view backend when a site cannot call Gemini, and tighter operator copy as the practice catalog grows.

Try it out

Prerequisites

Python 3.10+ and Node.js 20+
Expo Go (SDK 57) on a phone, or an emulator
A Google Gemini API key for live view naming
Optional: the Circular Capture Coach student package (34 practice images). Needed to retrain, to score published /sets, and to send Gemini the six exemplar photos. Point CAPTURE_COACH in api/config.py at that folder.

Quality weights already live in models/. You can run the server without retraining.

1. API server

From the repo root:

python -m pip install -r requirements.txt

Create a project .env (never commit it):

GEMINI_API_KEY=your_key_here

Optional:

ANALYZE_BACKEND=gemini
GEMINI_MODEL=gemini-3.1-flash-lite

Retrain only if you have the student package and want new quality weights (a few minutes):

python -m api.train

Start the server:

python -m uvicorn api.main:app --host 0.0.0.0 --port 8000

After any api/ change or retrain, restart Uvicorn so the phone and dashboard load the new code and weights.

Web dashboard: http://127.0.0.1:8000/dashboard/ (/ redirects there). Signed out, the navbar is the Scan-E logo only (no Storage / Analysis tabs). The sign-in card is a content-sized surface: Welcome!, then username, password, Sign in, and the hint “Use the same username and password as Profile on the phone.” First Sign in creates the account (username: letters, numbers, _; password 4+ characters). Sign in with that same phone username to see its library — this API already has photos for alejj12 (20) and alejj1216 (25). A different username is a different library. After sign-in, Storage shows the username in the navbar, a live photo count, and Refresh.

2. Phone app

Keep Uvicorn on port 8000. Metro proxies /model to that server.

cd mobile
npm install
npx expo start

Open the project in Expo Go. The phone must be able to reach the machine running Metro and the API. Campus Wi-Fi (for example Eduroam) often blocks phone-to-PC LAN; Expo’s tunnel stays available. If Uvicorn is down, Analysis stays on Analysis in Progress and Gemini never receives those calls.

Display previews are the stored originals. Only the upload copy is resized for analyze.

3. Checks

python -m api.check_api
python -m api.check_views
python -m api.check_account

Mobile:

node mobile/src/check_profile.js
node mobile/src/check_screens.js
node mobile/src/check_analyzeCache.js

check_views needs the student package. It posts every practice image the way a library file would (wrong chip, generic filename, JPEG recompress).

How to use it

Camera (phone). Bottom bar: Upload and Storage left of the shutter; session and Analyze on the right. Front / Rear / Label chips are hints. The shutter saves into the current camera set and stays on Camera. Upload saves unassigned photos and opens Storage. Analyze asks This session vs Storage. One photo in a session can be analyzed unassigned; two or more stay a set. Empty session: take a photo first. Empty storage sets: group photos into a set in Storage first.

Storage (phone and web). Filter All / Unassigned / Set N. Select photos, Create set, Add to set, Remove from set, Delete. Analyze only grouped (assigned) photos. After sign-in, grouping, delete, and analyze, the phone syncs the shared library when a session token exists. On the dashboard, Refresh re-pulls the snapshot, then each /account/photos/{id} image is fetched and shown as a blob URL. Tiles are a fixed 3/4 cell with min-height; the photo is both background-image and an <img> (cover) so the cell cannot collapse. Empty library copy is “No photos on {username} yet…” plus phone Sync now — not “All photos are in a set” (that line is only when photos exist and all are assigned).

Analysis. Photos appear immediately in a center-anchored roller (swipe to change the focused shot; hold one second to open Storage on the phone, or the in-page grid on the web). Cached shots show their last status right away. Until a new result arrives, the details card says Analysis in Progress. Then: status, Set N, view, Problem, Solution. Issue codes are not shown in the UI. A failed analyze keeps the photos on screen.

Profile. Person icon on Camera (overlay), Storage header, and the dashboard tab row after sign-in. Phone Profile has Sync now. The dashboard navbar shows the signed-in username; Sign out is in the dropdown.

Project layout

api/         FastAPI, features, training, inference, Gemini / local view backends
mobile/      Expo Go app (Camera, Storage, Analysis, Profile)
dashboard/   Web UI (StaticFiles at /dashboard/)
models/      blur_exposure.joblib, guidance.json
assets/      Scan-E logo
data/accounts/   Per-user library (gitignored)

Known limitations

Live view naming needs GEMINI_API_KEY. A missing key does not fall back to the local forest (api/backends/local_view.py is unused while Gemini is active).
Uncertain views are Needs review and do not fill that set’s checklist slot.
Gemini may see resized working copies of photos you analyze. Do not upload customer, credential, or production records.
The app does not verify device identity, ownership, or data destruction.
Practice-label matching (hash / IMG-#### filename / fingerprint) is for the student package so checks stay stable; unknown equipment goes through Gemini.
