Revit Airflow Designer

Tool to generate duct layout options in Revit

Comment

Dynamo: https://drive.google.com/open?id=0Bz0s8ADRQAW0b3BiUHdyUFRzRWM Addin: https://drive.google.com/open?id=0B-TPR6o2H5tmYmlrdWc0TkdIT0U

https://github.com/RevitAirflowDesigner/RevitAirflowDesigner

Built With

c#
dynamo
python

Submitted to

2017 AEC Technology Hackathon
- Winner Various Prize Choices!

Created by

I worked on the Revit addin part of the project. Analyzing the model, and building the mesh/nodes/edges to send for analysis. Then I worked on getting the analysis back, providing the information to the user, and the ultimate creation of Revit round ductwork and fittings.

A great team effort!

Matt Mason
I worked on the python code that received a mesh, generated mesh options, calculated performance metrics, and passed data back to Revit.

James McNeill
I worked on a bit of everything, between the revit addin and the python scripts.

Arif Hanif
Nathaniel G. MacDonald, E.I.T.
