Robot Diary Co-Pilot (3 wheeler rover)

•

  RoboRover

Inspiration

Robots are great at collecting data, but terrible at telling a simple story. I wanted a tiny rover that can narrate its day like a human: what it saw, what changed, and what mattered - without the cloud, privacy-preserving . That led to Robot Diary Co-Pilot: local image captions with LLaVA-7B and diary writing + Q&A with gpt-oss:20b (via Ollama), all over a home LAN.

What it does

• Captures images from a Pi camera as the rover drives.
• Shows a live timeline in a browser (laptop) with the latest photo + short caption.
• Lets you press Create travel diary (20B) to weave recent moments into a readable travel log (using gpt-oss:20b).
• Lets you Ask (20B) natural-language questions about the last N moments (e.g., “What changed in the last minute?”).
• Works fully offline (Pi + laptop, no cloud).

How I built it (2 scripts + a tiny camera bridge)

Pi (robot)

• pi/vision_bridge_gst.py — GStreamer pipeline that saves JPEG frames to /tmp/ov/current/ov%08d.jpg.

  • (Camera → libcamerasrc/v4l2src → jpegenc → multifilesink.)
• pi/diary_agent.py — Watches that folder, adds a lightweight overlay summary (state, risk, etc.), and POSTs the newest frame to the laptop portal every few seconds.

Laptop (Windows)

• diary_portal.py — A tiny Flask app that:
  • Receives pushes at /api/post and shows them on a timeline.
  • Calls Ollama locally: llava:7b for image captions and gpt-oss:20b for reasoning, Q&A, and diary writing.
  • Provides Ask (20B), Create travel diary (20B), and New Journey.

Model use

• All text reasoning/summaries/diary/Q&A are produced by gpt-oss:20b via Ollama.

• LLaVA:7B is used only for the (fast) image caption.

Architecture (offline, LAN only)

Camera → vision_bridge_gst.py (Pi) → JPEGs → diary_agent.py (Pi) → HTTP POST → diary_portal.py (Laptop) → Ollama: llava:7b + gpt-oss:20b → Timeline + Diary UI

Privacy by design • No cloud calls; all inference is on the local laptop via Ollama. • Images and generated text live in Documents/diary_data/ on the user’s machine. • The Pi can be air-gapped; only sends to the LAN laptop.

Why it satisfies the hackathon rule: the diary creation and all Q&A are produced by gpt-oss:20b running in Ollama on the laptop.

What I learned

• Keeping the prompt and context short is crucial for latency on local LLMs.
• Simple, windowed state makes “new journey” resets instant and prevents 20B from re-reading hundreds of old events.
• Troubleshooting Ollama on Windows benefits from small, repeatable PowerShell Invoke-RestMethod tests.

Challenges

• Time/out + endpoints: Mixing up /api/chat vs /api/generate (Ollama) produced 404s; default read timeouts were too short for 20B. Fixed using /api/generate and longer, configurable timeouts.
• Throughput vs quality: If the Pi posts too often, captions queue and stall. Solved with --min_interval_s and a lightweight “heartbeat”.
• Image orientation + clock drift: Added optional 180° rotation and normalized timestamps in the Flask view.
• Memory creep in the UI: The timeline could grow large; added a rolling window and a New Journey button to explicitly clear state.

What’s next

• Lightweight change detection on the Pi to only post when the view changes.
• Add map/location “breadcrumbs” to the diary (even coarse-grained).
• Export the diary as Markdown/PDF for sharing.

⸻

Built with (comma-separated list)

Python, Flask, HTML/CSS/JS, Ollama, gpt-oss:20b, LLaVA-7B, Raspberry Pi OS, PowerShell, curl, Requests, OpenCV-python-headless (optional), Pillow (optional)

(Note: the rover is a basic 3-wheel platform with a Pi5, Pi camera; a Hailo hat and a Arduino Nano are present but not required for this diary pipeline.)

Built With

• arduino-nano-(motor/io-control)
• flask
• gpt-oss:20b
• gstreamer
• hailo-hat-(optional)
• json
• llava:7b
• ollama
• opencv-python-(headless)
• powershell-7
• python-3.10
• raspberry-pi-5-+-pi-camera-(v3)
• windows-11
