Radar Tag

• The code is designed to control a PlutoSDR device for RF signal transmission
• It's specifically set up to generate and transmit a sine wave signal with controlled on/off patterns
• Key Parameters
• Center Frequency: 2.14 GHz (2140 MHz)
• Sample Rate: 10 MHz
• Transmission Gain: -70 dB
• Frame Size: 8192 samples
• Transmission Pattern
• Creates a pulsed transmission pattern:
  • 2 seconds ON (transmitting)
  • 1 second OFF (paused)
  • Repeats this cycle for 60 seconds total
• Signal Generation
• Generates a complex baseband sine wave at 1 kHz
• Uses amplitude of 0.9 to avoid saturation
• Implements proper sample timing for clean signal generation
• Status Monitoring
• Includes a real-time status display window
• Shows current transmission status
• Displays key parameters like frequency and sample rate
• Provides cycle count updates
• Project Structure The repository contains several related components:
• RF signal analysis tools
• LoRa communication testing
• Antenna testing utilities
• Various SDR configuration scripts

Built With

• libiio
• matlab
