Parallax

Turn an outfit reference into a virtual fitting and an interactive 3D look.

Description

Parallax is a virtual fitting and 3D fashion platform. A user uploads a clear photo of themselves and provides an outfit image or a public Instagram post. Parallax identifies the available clothes, lets the user choose one look, and uses the YouCam Clothes API to create a virtual try-on.

After the user approves the fitting, Parallax creates 12 consistent views of the same person and outfit. Those views are checked for identity, pose, clothing, color, and camera order before GPU reconstruction begins. The final result is an interactive, full-color 3D look that can be rotated, inspected, relit when supported, and downloaded from the dashboard.

Three consistent views of the same fitted look

Impact

Online clothing decisions are usually based on product photos or a single flat preview. That makes it difficult to understand how a complete outfit may look on a specific person from different directions.

Parallax addresses this problem by connecting virtual fitting with 3D review:

Shoppers can compare an outfit with their own appearance before making a decision.
Social media inspiration can become a selectable fitting instead of remaining a screenshot or saved post.
Multiple outfits found in one reel can be separated and shown as clear choices.
Designers and retailers can present a fitted look from every direction without arranging a new photo shoot for each view.
A consistent 3D result gives users more information than a single generated image.

How we integrated the YouCam API

YouCam Clothes v3 is the fitting layer at the center of the workflow.

The user uploads a front-facing identity photo.
The user uploads an outfit image or pastes a public Instagram post or reel.
For social media input, Parallax extracts useful frames and groups distinct outfits.
The user selects the exact outfit they want to try.
The backend sends the protected identity image and selected garment image to YouCam Clothes v3.
Parallax polls the YouCam task and returns the completed fitting to the dashboard.
The user reviews the result before any 3D processing starts.
Once approved, the fitting becomes the locked reference for the 12-view and reconstruction pipeline.

YouCam credentials remain on the server. They are never sent to the browser or stored in frontend code.

What we used

Area	Technology	Purpose
Virtual fitting	YouCam Clothes v3	Applies the selected clothing to the user's photo
Backend	Python, FastAPI, Pydantic, Uvicorn	Handles uploads, jobs, polling, validation, and artifacts
Social media intake	yt-dlp, gallery-dl, FFmpeg	Reads public posts and selects useful clothing frames
Multiview pipeline	Controlled view synthesis and consistency checks	Creates a fixed 12-view orbit while protecting identity and clothing
3D reconstruction	Nerfstudio Splatfacto	Builds a face-preserving, full-color Gaussian model
Mesh reconstruction	Hunyuan3D multiview	Builds a textured mesh that supports directional lighting
GPU runtime	NVIDIA A100, CUDA, PyTorch	Accelerates reconstruction and texture processing
3D viewer	Three.js, SparkJS	Displays GLB, PLY, and Gaussian results in the browser
Deployment	Docker, systemd, Caddy	Runs isolated workers and serves the public HTTPS application

Example

A user finds an Instagram reel containing three outfits. They upload one front-facing photo and paste the reel URL into Parallax.

Parallax extracts the clearest clothing frames and presents the three outfits as separate options. The user selects a pink and white jacket. YouCam Clothes v3 fits that jacket to the user's photo, and the dashboard shows the result for approval.

After approval, Parallax keeps the same face, pose, jacket construction, colors, and accessories while creating 12 camera views at 30 degree intervals. The quality layer checks the views, and the A100 worker reconstructs them into a full-color 3D result. The user can rotate the model, inspect the outfit from the back and sides, adjust lighting on a mesh result, and download the final artifact.

Background-removed fitted subject

System architecture

flowchart LR
    User[User] --> Web[Parallax dashboard]

    subgraph Input[Input]
        Photo[Identity photo]
        Social[Instagram post or reel]
        Upload[Outfit image]
    end

    Photo --> API[FastAPI service]
    Social --> Media[Frame extraction]
    Upload --> API
    Media --> Choices[Distinct outfit choices]
    Choices --> API
    Web --> API

    API --> YouCam[YouCam Clothes v3]
    YouCam --> Preview[Virtual fitting preview]
    Preview --> Approval{User approval}
    Approval --> Lock[Identity and outfit lock]
    Lock --> Views[12 consistent camera views]
    Views --> Audit[Quality and coherence checks]
    Audit --> Worker[A100 reconstruction worker]

    Worker --> Splat[Full-color Gaussian model]
    Worker --> Mesh[Textured mesh]
    Splat --> Viewer[Interactive 3D viewer]
    Mesh --> Viewer
    Viewer --> User

    Store[(Job and model storage)] --- API
    Store --- Worker

    classDef fitting fill:#ffe4ee,stroke:#f43f7a,color:#241820;
    classDef process fill:#f1edff,stroke:#8b5cf6,color:#241820;
    classDef compute fill:#eaf8ff,stroke:#269ac8,color:#241820;
    class YouCam,Preview,Approval fitting;
    class Lock,Views,Audit process;
    class Worker,Splat,Mesh compute;

Request flow

sequenceDiagram
    actor U as User
    participant D as Dashboard
    participant A as FastAPI
    participant Y as YouCam Clothes v3
    participant Q as Multiview quality layer
    participant G as A100 3D worker

    U->>D: Upload photo and outfit source
    D->>A: Create fitting job
    A-->>D: Return outfit choices when needed
    U->>D: Select one outfit
    A->>Y: Submit identity and garment
    Y-->>A: Return virtual fitting
    A-->>D: Show fitting preview
    U->>D: Approve result
    D->>A: Start 3D job
    A->>Q: Create and check 12 views
    Q->>G: Send verified views and cameras
    G-->>A: Return PLY or GLB model
    A-->>D: Display interactive result

Pipeline rules

The 3D stage uses explicit rules because a set of attractive images is not automatically a valid reconstruction dataset.

The approved YouCam fitting is the canonical identity and clothing reference.
The camera follows a fixed orbit with known azimuth and elevation values.
Identity, pose, garment structure, color, and accessories are compared across views.
Repair passes correct major drift without rejecting small visual differences.
Foreground masks prevent the studio background from becoming part of the model.
Known camera transforms remove the need to estimate synthetic camera positions.

Run the project

Requirements

Ubuntu 22.04 or newer
Python 3.10 or newer
Docker Engine and NVIDIA Container Toolkit
CUDA-capable GPU, with NVIDIA A100 recommended
YouCam Clothes v3 API credentials
A configured multiview processing service
A DNS name or reverse proxy for HTTPS

Install

git clone https://github.com/Harry-2005/YouCam-3D.git
cd YouCam-3D

sudo install -d -m 0755 /tmp/nerfstudio-deploy
sudo cp -a deploy/. /tmp/nerfstudio-deploy/
sudo cp -a frontend /tmp/nerfstudio-deploy/frontend

sudo bash deploy/bootstrap.sh
sudo bash deploy/install.sh

Install the YouCam credential file on the server and restart the API:

sudo install -m 0600 /secure/path/youcam-creds.txt \
  /opt/nerfstudio-api/.youcam-api-key
sudo systemctl restart nerfstudio-api caddy

Verify the deployment:

curl https://your-domain.example/health
sudo systemctl is-active nerfstudio-api caddy docker
nvidia-smi

See deploy/README.md for the full host layout and deployment procedure.

API example

Create a YouCam fitting job:

curl -X POST "$BASE_URL/v1/style-jobs" \
  -F "[email protected]" \
  -F "[email protected]" \
  -F "garment_category=auto"

Poll GET /v1/style-jobs/{style_id} and review the returned fitting. Approve it to start the 3D pipeline:

curl -X POST "$BASE_URL/v1/style-jobs/$STYLE_ID/approve" \
  -F "method=splatfacto" \
  -F "iterations=10000"

Read the pipeline status and download the completed model:

curl "$BASE_URL/v1/pipelines/$PIPELINE_ID"
curl -L -o model.zip "$BASE_URL/v1/pipelines/$PIPELINE_ID/model"

Repository structure

.
|-- deploy/
|   |-- app.py
|   |-- hunyuan_generate.py
|   |-- clean_textured_mesh.py
|   |-- bootstrap.sh
|   |-- install.sh
|   `-- nerfstudio-api.service
|-- frontend/
|   |-- index.html
|   |-- studio.html
|   |-- styles.css
|   `-- app.js
|-- docs/assets/
|   |-- parallax-wordmark.svg
|   |-- hero-subject.png
|   `-- orbit-views.png
`-- .github/workflows/ci.yml

Security

YouCam credentials stay on the server.
Credential files, generated models, browser profiles, and job archives are ignored by Git.
Upload validation limits file size and accepted media types.
Archive extraction rejects path traversal and symbolic links.
The service runs as a restricted, non-login system user.
