NeuroCreative-copilot

CTR decay forecasting and perception analysis to build a creative health monitor that tells you which ads are fatiguing, why, and what to do about it.

Comment

NeuroCreative Copilot

AI-powered creative intelligence for mobile advertisers.

NeuroCreative Copilot analyzes ad creatives through a brain-inspired cognitive lens and tells marketers whether to Scale, Monitor, Pivot, or Pause each creative — backed by ML fatigue prediction, CTR decay modeling, and neuro-inspired attention/reward/memory scoring.

Built for the Smadex Creative Intelligence Challenge at HackUPC 2026.

Quick Start

Option A: One-Click Launch (Recommended)

:: From the repo root (one folder up from this README):
START.bat

Open http://localhost:5173. Done. The script handles everything.

Option B: Manual Start

# 1. Install Python dependencies
pip install fastapi uvicorn python-multipart sse-starlette pandas numpy scipy scikit-learn lightgbm Pillow joblib

# 2. (Optional) Add LLM keys for smarter copilot answers + TRIBE endpoint
cp .env.example .env
# Edit .env: OPENAI_API_KEY, GOOGLE_API_KEY, TRIBE_ENDPOINT

# 3. Start backend (port 8000)
python api_server.py

# 4. Start frontend (port 5173)
cd dashboard/artifacts/neurocreative
npm install
npm run dev:frontend

See INSTRUCTIONS FOR DEMO.md (repo root) for full demo guide.

What It Does

  1. Upload raw Smadex CSV files (creative_summary, creatives, campaigns, advertisers, daily_stats)
  2. Pipeline runs live: joins tables, extracts brain features, fits decay curves, trains ML model, generates recommendations
  3. Or upload a creative image/video on the Copilot page: TRIBE V2 brain inference + LightGBM v3 prediction → executive summary (A-F grade) + brain scores + decay forecast + heatmap + improvements
  4. Dashboard shows 1080 creatives with KPIs, brain scores, MRI visualization, fatigue risk, and action recommendations
  5. Copilot chat answers follow-up questions about any creative via streaming AI agent with 4 analysis tools

Upload Modes

What you upload What happens
All 5 Smadex CSVs Full live pipeline: decay curves + ML predictions + brain features + recommendations
Just creative_summary.csv Pipeline with heuristic decay, ML predictions from available columns
Single CSV with creative_ids Fast match against pre-computed data (75 real TRIBE V2 + 1005 imputed)
Creative image/video (Copilot page) TRIBE V2 brain scores + PIL features → 77-feature LightGBM v3 → executive summary (A-F grade) + brain scores + decay forecast + heatmap + improvements + agent chat

Architecture

  Smadex CSVs (uploaded)          Python Backend                React Dashboard
  ┌──────────────────┐     ┌────────────────────────┐     ┌──────────────────┐
  │ creative_summary  │     │                        │     │                  │
  │ creatives         │────>│ pipeline_runner.py     │────>│  KPI cards       │
  │ campaigns         │     │  detect → join → brain │     │  Creative gallery │
  │ advertisers       │     │  → decay → ML → recs   │     │  Brain scores     │
  │ daily_stats       │     │                        │     │  MRI heatmap      │
  └──────────────────┘     │ api_server.py           │     │  Copilot chat     │
                             │  FastAPI + SSE streaming │     │                  │
  User asks question ─────>│ POST /api/ask-copilot   │────>│  Streaming answer │
                             └────────────────────────┘     └──────────────────┘

  Creative (image/video)       Copilot Pipeline                    Copilot Page
  ┌──────────────────┐     ┌────────────────────────────────┐     ┌──────────────────┐
  │ apple_ad.png      │     │ POST /api/copilot/analyze      │     │                  │
  │ nike_ad.png       │────>│  PIL → TRIBE → ML → heatmap   │────>│  Grade card (A-F) │
  │ any creative      │     │  → decay → summary → recs     │     │  Brain gauges     │
  └──────────────────┘     │                                │     │  Decay chart      │
                             │ POST /api/copilot/chat         │     │  Heatmap          │
  Follow-up questions ─────>│  CopilotAgent (4 tools)        │────>│  Improvements     │
                             │  GPT-4o → Gemini → rule-based  │     │  Agent chat       │
                             └────────────────────────────────┘     └──────────────────┘

Tech Stack

Layer Tech
Backend Python, FastAPI, SSE-Starlette, pandas, numpy, scipy, scikit-learn, LightGBM
Frontend React 19, Vite 6, TypeScript 5.9, Tailwind CSS 4, shadcn/ui, Recharts
Copilot LLM OpenAI GPT-4o (primary) / Google Gemini 2.5 Flash (fallback) / rule-based (no-key fallback)
ML LightGBM v3 boosted (status classifier 76.4% + fatigue regressor + perf regressor, 77 features)
Brain Scoring TRIBE V2 neural model (Kaggle P100 GPU) + LightGBM-imputed + heuristic formulas
Streaming Server-Sent Events (SSE) for real-time copilot responses + image analysis progress
Caching Hash-based JSON cache (tmp/cache/) with numpy serialization

AI/ML Models

Model What it does Required?
TRIBE V2 Real neural brain encoding model (attention, reward, memory, emotion, visualLoad) Optional (Kaggle GPU + TRIBE_ENDPOINT in .env)
LightGBM v3 Status Predicts creative status: top_performer / stable / fatigued / underperformer (76.4% acc) Optional (heuristic fallback)
LightGBM v3 Fatigue Predicts continuous fatigue probability (0-1) Optional (heuristic fallback)
LightGBM v3 Perf Predicts performance score (0-100) Optional (neural efficiency fallback)
OpenAI GPT-4o-mini Generates copilot chat answers about creatives Optional (.env key)
Google Gemini 2.0 Flash Alternative copilot LLM Optional (.env key)
scipy curve_fit Fits exponential CTR decay curves per creative Optional (linear fallback)
Custom brain formulas Computes attention, reward, memory, emotion, visual_load from visual metadata Always works (numpy only)

Project Structure

NeuroCreative-copilot/
  api_server.py              FastAPI backend — upload, copilot SSE, image analysis, asset serving
  pipeline_runner.py         Live pipeline — detect tables, run analysis, generate outputs
  copilot_agent.py           Copilot agent — 4 tools, executive summary, heatmap, multi-LLM
  image_features.py          PIL feature extraction (19 features: brightness, contrast, edges, symmetry...)
  ml_predictor.py            Pre-trained LightGBM v3 boosted predictions (77 features)
  copilot_prompts.py         System prompt + neuroscience knowledge base + context builders
  video_features.py          OpenCV video frame extraction (for video analysis)
  tribe_client.py            Remote TRIBE V2 client (Kaggle GPU via cloudflared)
  cache_manager.py           Hash-based JSON cache with numpy serialization
  pipeline_logger.py         Structured rotating log (logs/pipeline.log)
  healthcheck.py             Backend health check script (used by START.bat)
  data/                      Pre-computed pipeline outputs (TRIBE V2 integrated)
  models/                    Trained LightGBM v3 boosted models (77 features)
  assets/                    Creative images (apple_ad.png, nike_ad.png, etc.)
  tmp/cache/                 Cached analysis results (JSON, keyed by file hash)
  tmp/copilot/               Copilot analysis cache (JSON, keyed by file hash)
  tmp/uploads/               Copilot uploaded files (static mount /tmp-uploads/)
  pipeline/
    creative_intelligence/   Original 7-step pipeline scripts (offline, re-runnable)
    time_decay/              Alternative XGBoost AFT survival pipeline
    backend_api.py           Standalone TRIBE v2 live inference server (GPU/Colab)
  dashboard/
    artifacts/neurocreative/ React/Vite frontend dashboard
  INTEGRATION.md             Full architecture documentation
  CHANGELOG.md               Detailed change history

../
  START.bat                  One-click launcher (auto-installs, starts everything, auto-restarts)
  INSTRUCTIONS FOR DEMO.md   Complete demo guide
  creative_intelligence_pipeline/  ML pipeline scripts + data + charts + docs

Pipeline Details

The live pipeline (pipeline_runner.py) runs these steps on every upload:

Step Function Hard Dependency Fallback
1. Detect tables detect_tables() pandas + numpy —
2. Build master build_master_table() pandas Uses whatever tables available
3. Daily fatigue build_daily_table() pandas Skips if no daily stats
4. Brain features compute_brain_features() pandas + numpy Uses available columns only
5. Decay curves compute_decay_features() scipy Linear decay heuristic
6. ML predictions compute_predictions_ml() lightgbm Rule-based heuristics
7. Recommendations generate_recommendations() pandas Always works

Brain Feature Formulas

Computed from visual metadata (no GPU needed):

  • Attention = 0.40 x motion + 0.30 x novelty + 0.20 x clutter + 0.10 x has_duration
  • Reward = 0.30 x brand_visibility + 0.25 x has_discount + 0.25 x has_price + 0.20 x product_count
  • Memory = 0.35 x readability + 0.25 x (1 - text_density) + 0.25 x brand_visibility + 0.15 x novelty
  • Emotion = 0.40 x tone_encoding + 0.30 x faces + 0.20 x ugc_style + 0.10 x motion
  • Visual Load = 0.35 x clutter + 0.35 x text_density + 0.20 x product_count + 0.10 x motion

API Endpoints

POST /api/analyze-creatives-upload

  • Input: Multipart form with files (one or more CSVs)
  • Output: DashboardResponse JSON with creatives, KPIs, brain scores, recommendations
  • Logic: Auto-detects table types, runs live pipeline, returns results

POST /api/analyze-creative-image

  • Input: Multipart form with file (PNG/JPG image)
  • Output: SSE stream with 7 progress events + final analysis result
  • Pipeline: PIL features → TRIBE V2 brain → LightGBM v3 boosted → recommendation

POST /api/ask-copilot

  • Input: JSON { question, selectedCreative, dashboardContext }
  • Output: SSE stream — token events + final structured response
  • Logic: Context-aware answers from pipeline data

POST /api/copilot/analyze

  • Input: Multipart form with file (image or video)
  • Output: SSE stream — 7 progress steps with real timing + final CopilotAnalysis
  • Report includes: Executive summary (A-F grade), brain scores, decay forecast chart, attention heatmap, improvements, ML recommendation
  • Features: Caching in tmp/copilot/, is_mock_data flag, total_processing_time, step_timings

POST /api/copilot/chat

  • Input: JSON { message, analysis_ids, history }
  • Output: SSE stream — thinking/tool_call/tool_result/token/done events
  • Agent tools: forecast_decay, explain_brain_scores, suggest_improvements, compare_creatives

POST /api/copilot/compare

  • Input: JSON { analysis_ids } (min 2)
  • Output: JSON comparison with winner, insights, dimension breakdown

POST /api/copilot/reset

  • Output: JSON { ok, cleared_cache, cleared_uploads }
  • Logic: Deletes all tmp/copilot/*.json and tmp/uploads/* files

GET /assets/{filename}

  • Serves creative PNG images

Branches

Branch Content
main Base: README + TRIBE v2 notebook
EDA 4 Jupyter notebooks, master table, daily fatigue, insights
WEB React dashboard (standalone, pre-integration)
integration Current: Full stack with TRIBE V2, live pipeline, trained ML, SSE streaming copilot
