AxiomZen - Mastermind API

This is the API for the AxiomZen challenge on Vanhackathon.

Comment 3

mastermind

AxiomZen challenge on Vanhackathon

The challenge consists on creating an API that allows creation of mastermind games, waits for players to join and check their guesses.

Requirements for local execution

  • Ruby 2.3.0
  • Rails 4.2.6
  • Postgresql

Executing on local machine

  1. gem install bundler
  2. bundle install
  3. foreman start

Requirements for docker execution

  • Docker v1.11.1 or higher
  • Docker Compose v1.7.1 or higher

Executing on docker

  1. Enter the directory of the project
  2. Build the docker image with docker build -t mastermind-api:v1 .
  3. Start the service with docker-compose up or connect to the docker container with docker-compose run --rm --service-ports api bash

API

This project consists of the following APIs:

POST /games

  • Creates a game;
  • Headers:
    • Accept: application/json
    • Content-Type: application/json
  • Input:
    • player: Name of the player creating the game;
    • number_of_players: Number of people that will play the game. Defaults to 1;
    • allow_repetition: Indicates if the code generated will have duplicated colors or not. Defaults to false;
    • max_turns: The max number of guesses each player will have. If it isn't present, the game will run on endless mode;
    • Example: { "player": "Player1", "number_of_players": 2, "allow_repetition": true, "max_turns": 10 }
  • Output: check schema Game

GET /games/:game_key

  • Gets a game by game_key
  • Headers:
    • Accept: application/json
  • Input:
    • game_key: Identifier of the game;
    • Example: /games/jHSZDdLHb3QpbRajXv9bzvCX
  • Output: check schema Game
    • There are no guesses in this response, except when the game is over;
    • Example: {"game_key":"NApe9saManED9vcqUsCSmf1u","status":"playing","number_of_players":2,"max_turns":10,"allow_repetition":true,"code_length":8,"colors":["R","B","G","Y","O","P","C","M"],"current_turn":1,"players":["GameMaster","John Doe"]}
    • Example of finished game: {"game_key":"NApe9saManED9vcqUsCSmf1u","status":"finished","number_of_players":2,"max_turns":10,"allow_repetition":true,"code_length":8,"colors":["R","B","G","Y","O","P","C","M"],"current_turn":11,"players":["GameMaster","John Doe"],"winner":null,"guesses":{"GameMaster":[{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"BBBBBBBB","exact":1,"near":0},{"code":"BBBBBBBB","exact":1,"near":0},{"code":"BBBBBBBB","exact":1,"near":0},{"code":"BBBBBBBB","exact":1,"near":0},{"code":"BBBBBBBB","exact":1,"near":0}],"John Doe":[{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0}]}}

GET /games/availables

  • Gets all available games a player can enter
  • Headers:
    • Accept: application/json
  • Output: An array of available games. Check schema Game
    • free_slots: present only in this API, shows how many more players can enter a game;
    • Example: [{"game_key":"g3sqc3e22BARHDA45rj7Ad2T","status":"waiting_for_players_to_join","number_of_players":2,"max_turns":10,"allow_repetition":true,"code_length":8,"colors":["R","B","G","Y","O","P","C","M"],"players":["GameMaster"],"free_slots":1}]

POST /games/:game_key/players

  • Joins a game;
  • Headers:
    • Accept: application/json
    • Content-Type: application/json
  • Input:
    • game_key: Identifier of the game;
    • player: Name of the player joining the game;
    • Example: { "player": "John Doe" }
  • Output: check schema Game
    • Example: {"game_key":"NApe9saManED9vcqUsCSmf1u","status":"playing","number_of_players":2,"max_turns":10,"allow_repetition":true,"code_length":8,"colors":["R","B","G","Y","O","P","C","M"],"current_turn":1,"players":["GameMaster","John Doe"],"player_key":"sGXdaw2pPhG91NT7TincTtVZ","my_guesses":[]}

POST /players/:player_key/guesses

  • Makes a guess in a game with a given user;
  • Headers:
    • Accept: application/json
    • Content-Type: application/json
  • Input:
    • player_key: Identifier of the game;
    • code: Guess made by the player
    • Example: { "code": "RBGRBGRB" }
  • Output: check schema Game
    • Example: {"game_key":"NApe9saManED9vcqUsCSmf1u","status":"playing","number_of_players":2,"max_turns":10,"allow_repetition":true,"code_length":8,"colors":["R","B","G","Y","O","P","C","M"],"current_turn":3,"players":["GameMaster","John Doe"],"player_key":"nbRkoTYHdVyP6TyRb5jvmvCP","my_guesses":[{"code":"RRRRRRRR","exact":3,"near":0},{"code":"RRRRRRRR","exact":3,"near":0}]}

Schema Game

- game_key: The identifier of the game;
- status: The current status of the game. Can be `waiting_for_players_to_join`, `playing` or `finished`;
- number_of_players: Number of players on the game;
- max_turns: The max number of guesses each player will have;
- allow_repetition: Indicates if the code generated will have duplicated colors or not;
- code_length: The length of the code that the players must guess;
- colors: Array of all colors possibles;
- current_turn: The current turn of guesses;
- players: Array of names of all players that joined the game. *Only present when the game has not finished*;
- player_key: The identifier of the player. *Only present when the game has not finished*;
- my_guesses: Array of guesses from the current player. Each entry contains the code inputed, the amount of exact and amount of near colors. *Only present when the game has not finished*;
- winner: Name of the winner of the game, if any. *Only present when the game has finished*;
- guesses: All guesses separated by user. *Only present when the game has finished*;
- Example: `{"game_key":"9nUdqDBHp1X6SbuxsF3tZSfM","status":"playing","number_of_players":2,"max_turns":10,"allow_repetition":true,"code_length":8,"colors":["R","B","G","Y","O","P","C","M"],"current_turn":1,"players":["GameMaster","John Doe"],"player_key":"JewMZX8mYcrAS3iNMFsWewbh","my_guesses":[{"code":"MOMGYBRY","exact":2,"near":1}]}`

Jobs

To avoid keeping old games open, after 5 minutes of inactivity the game will be closed. To do so, a job is being used. Whenever the game is updated, it schedules a job for the next 5 minutes, so it can check if there was any update during this time.

Trying it out

This application is currently hosted on Heroku. To test it, use the url https://mastermind-challenge.herokuapp.com in combination with the paths posted above. Please note that the free account of Heroku allows only one active dyno at a time. Because of this, the games are not being closed due to inactivity. When testing locally, though, this works as intended.

Testing the code

To test the code, use the command rspec spec
