Inspiration

The shape of the problem

Sam, a delivery operator at a boutique restoration house, clears a library through a streamer's automated QC gate. The rejection slip says loudness failed. It does not say where. Render-farm SRE dashboards in this hackathon lane watch CPU and queue depth. They do not file a film's own loudness into Grafana Cloud and close the alert only on a second measurement.

Interlock talks to Grafana only through the official grafana/mcp-grafana MCP server. Remove that path and there is no folder, no dashboard, no annotation, no alert rule, and no close. Measured close on Night Tide: repaired to -23.1 LUFS, landed=True, Grafana's own alert state history showed Alerting then Normal. Honest limit: each title is a stated window (120 s or 300 s), not a full-length scan.

A restoration house delivers a title to a streamer, and a machine on the other end rejects it. The slip that comes back says the audio failed loudness. It does not say where. Somebody then sits with the whole feature and a meter, finds the reel that runs quiet, fixes it, and re-delivers, and the queue behind them does not move while they do.

The measurement that would have told them where is not hard. ffmpeg -af ebur128 prints a loudness reading every 100 milliseconds, and has for years. Point it at Vicki (1953) off archive.org and it says the first 300 seconds sit at -26.1 LUFS against a -23 target:

curl -L -r 0-24000000 -o vicki.mp4 \
  "https://archive.org/download/vicki-1953/Vicki%20%281953%29.mp4"
ffmpeg -hide_banner -i vicki.mp4 -t 300 -af ebur128=peak=true -f null -
# Integrated loudness:  I: -26.1 LUFS

So the numbers exist. Interlock treats them the way an SRE team treats a service: a film archive is a fleet, every title is a service, the delivery spec is its objective, and every second of programme audio outside the loudness corridor burns error budget.

What it does

Interlock takes eight public-domain features, measures each one with ffmpeg, and files the failures into Grafana Cloud through the official grafana/mcp-grafana MCP server. Then it does the thing an observability agent normally stops short of: it repairs a master, measures the file it wrote, and resolves its own alert on that second number.

Two things about that are unusual.

The series on the Grafana panel is the film's own loudness. Not the CPU of a render node, not a job queue depth. One sample every 100 milliseconds, straight out of ffmpeg's ebur128 filter, over films anyone can download and re-measure.

The film's own loudness, one sample per 100 ms

The alert is closed by a second measurement, not by the repair exiting zero. The repair runs a two-pass loudnorm, writes a new file, and a third ffmpeg pass measures that file. RepairResult.landed is arithmetic over the number that pass returned. A loudnorm run that exits zero and moves nothing arrives with landed false and the alert stays open.

The two gates that decide whether a record closes

One run

START -> survey -> probe -> measure_fleet -> triage -> file -> repair -> review -> close -> publish
                                                        |                                    ^
                                                        +---- hold --------------------------+

Nine nodes in a google.adk.workflow.Workflow, six functions and three LlmAgents, one branch taken on a structured boolean so the shape of the run is reproducible while the judgement inside it is not.

node	what it does
`survey`	Gemini, holding an ADK `McpToolset` over mcp-grafana, discovers the stack's datasources and picks the ones this run writes to
`probe`	Attempts every Grafana write for real against a scratch folder and dashboard, and records the refusals verbatim
`measure_fleet`	ffmpeg `ebur128` over each title, 100 ms momentary and 3 s short-term, plus caption checks
`triage`	Gemini ranks the fleet, picks the title to escalate, decides whether one gain change delivers it
`file`	Folder, dashboard, one annotation per breach span at its timecode, alert rule create
`repair`	Two-pass `loudnorm`, then a third pass that measures the file it wrote
`review`	Gemini, which can withhold closure and cannot grant it
`close`	Writes the re-measured figure into the alert rule and waits for Grafana to clear it
`publish`	The fleet board and the run record the web surface renders

Every node writes one line into the run record as its last act, so the trace on screen is what executed rather than what the diagram promises. Here is a full eight-title run:

mcp calls       70
nodes executed  survey[llm] -> probe -> measure_fleet -> triage[llm] -> file
                -> repair -> review[llm] -> close -> publish
  survey        Gemini called list_datasources, query_loki_logs and chose series
                datasource grafanacloud-infinity, alert state history
                grafanacloud-alert-state-history
  probe         9 capabilities attempted for real, escalation path alert_rule
  measure_fleet 8 titles measured with ffmpeg ebur128, 11408 samples at 100 ms
  triage        Gemini queued 8 titles, escalate='memphis_belle', severity='critical',
                auto_repairable=False, repair_target='night_tide'
  file          filed ['memphis_belle', 'night_tide'] into Grafana, routed to repair
  repair        loudnorm two-pass on night_tide, re-measured -23.1 LUFS, landed=True
  review        Gemini approve=True, residual_work='none'
  close         closed=True on the re-measurement, gate: both gates passed
  publish       fleet board written, 18 assertions
post-conditions 18 of 18 hold

Read the triage line closely, because it is the model earning its place. The Memphis Belle is the worst title in the fleet and Gemini escalated it, then refused to auto-repair it, because its true peak is already over the ceiling and a gain change would clip. It nominated a different title for the repair, and the branch took repair on that one instead.

Which nodes ran, and what each one did

Scope

Each title is measured over a stated window, printed beside every figure, because eight features at full length is minutes of ffmpeg per pass. The repair corrects a level offset; out-of-corridor spans caused by a dead reel or a blown optical track survive it, which is why they are filed as annotations at their timecodes for a person.

Two of the eight titles pass the spec outright, and that matters more than the six that fail. An SLO that condemns every title is indistinguishable from a broken measurement.

title	window	integrated	true peak	availability	verdict
The Memphis Belle (1944)	120 s	-10.7 LUFS	+0.9 dBTP	30.29%	critical
Police Station (1959)	120 s	-25.9 LUFS	-14.9 dBTP	72.70%	critical
Vicki (1953)	300 s	-26.1 LUFS	-13.5 dBTP	75.27%	critical
Werewolf In A Girls Dormitory (1961)	120 s	-22.0 LUFS	-4.3 dBTP	85.32%	major
Night Tide (1961)	120 s	-17.4 LUFS	-4.4 dBTP	83.36%	major
Fit for a King (1937)	120 s	-21.0 LUFS	-4.1 dBTP	100.00%	minor
Niagara Falls (1941)	120 s	-22.3 LUFS	-9.3 dBTP	100.00%	clear
Night of the Living Dead (1968)	120 s	-24.0 LUFS	-10.1 dBTP	99.20%	clear

What it refuses to guess

A criterion that could not be measured is never a pass. If ffmpeg returns no true peak block, the ceiling was not checked, so the title reads NOT MEASURED with the reason rather than in spec. The same holds for a window that sits entirely below the -70 LUFS absolute gate, where the availability arithmetic would otherwise return a reassuring 100% over programme audio that is not there. A record cannot close on a check that could not fail.

The repair writes audio only, so caption findings travel from the master's own sidecar rather than being re-measured on the repaired file, where they would come back clean because there is nothing to measure.

How we built it

Grafana Cloud MCP is load-bearing, not a sidecar. Interlock holds no Grafana HTTP client. Every call is a tool call on grafana/mcp-grafana, held as a child process over stdio. A demo that only painted a dashboard without MCP writes would fail this track; the five write classes below are the compliance proof. Five write classes land per run: create_folder, update_dashboard, create_annotation once per breach span at its media timecode, alerting_manage_rules create, then the same rule updated with the re-measured figure. Reads that prove them: get_dashboard_by_uid, get_annotations by a tag minted by this run, grafana_api_request GET /api/prometheus/grafana/api/v1/rules polled until the ruler settles, and query_loki_logs against grafanacloud-alert-state-history.

Nothing reports success from a 200. An accepted alerting_manage_rules create means Grafana received a JSON document, so the run polls the ruler until the rule reaches firing, and after the repair polls it again until inactive. The strongest assertion in the product is the one Interlock cannot write: Grafana logs its own alert state transitions into a Loki stream that Interlock only ever reads.

PASS  Grafana evaluated rule cfxr32fygp2bkc to firing
      reached firing after 52s, states seen: ['unknown', 'inactive', 'firing']
PASS  Grafana evaluated rule afxr359kjzw1sa to inactive
      reached inactive after 16s, states seen: ['firing', 'inactive']
PASS  alert rule afxr359kjzw1sa has state transitions in Grafana's own history
      states seen: ['Alerting', 'Normal']
      LogQL: {from="state-history"} | json | ruleUID=`afxr359kjzw1sa`

The delivery record, read back out of Grafana Cloud

The agent drives the toolset, not a query string. The first node is an LlmAgent holding google.adk.tools.mcp_tool.McpToolset over that same server. ADK connects, reads the tool list off the server, and hands Gemini each tool with mcp-grafana's own JSON schema, so the model picks the call and shapes the arguments. On this stack it called list_datasources and query_loki_logs, chose grafanacloud-infinity to carry the 100 ms series and grafanacloud-alert-state-history to prove a rule fired.

That answer is load-bearing rather than decorative. Every uid it names is read back from Grafana before anything is written, and one that does not resolve stops the run, because a dashboard saved against an invented datasource uid renders an empty panel and Grafana accepts that write happily. The agent chooses, Grafana adjudicates, neither is trusted alone.

tool_filter is an allowlist of that server's 21 read tools. mcp-grafana offers 81 here and 20 of them mutate the stack, including update_dashboard. A model sent to describe the stack must not be able to overwrite the delivery record while it looks around.

Gemini discovering the stack through mcp-grafana

Google ADK and Gemini, with the numbers kept deterministic. The graph is a Workflow with a routing map on file, so the same fleet takes the same path twice. Three nodes are LlmAgents with Pydantic output_schemas, and each one changes what executes: survey picks the datasources, triage picks the title and decides whether repair runs at all, review can withhold closure. Every number they see came out of ffmpeg and none of them produce one.

Remove the Gemini credentials and the run stops before ffmpeg starts. GEMINI_MODEL alone is not enough, because with Vertex the SDK also needs a project and a location, and without them the old failure arrived inside the triage node after the whole fleet had been measured. Nine tests take one credential away each and assert the refusal happens before any MCP session opens.

Deployed on Cloud Run, with the Grafana token supplied from Secret Manager at runtime and never in the image. The deployed service runs the whole graph, not just the page it serves: POSTing two title ids to /api/run and polling /api/status to a terminal state executed all nine nodes against live Grafana Cloud and Vertex Gemini in 2 minutes 32 seconds, 46 MCP calls with 13 writes, 10 of 10 post-conditions, the series read back out of Grafana at 1,203 rows matching ffmpeg to 0.001 LUFS, and the record closed on the re-measurement.

The delivery record on Cloud Run

Built with: Python 3.13, ffmpeg (ebur128, loudnorm), Google ADK (google.adk.workflow.Workflow, LlmAgent, McpToolset), Gemini 2.5 Flash on Vertex AI, grafana/mcp-grafana v1.3.0, Grafana Cloud (dashboards, annotations, Grafana-managed alerting, Loki alert state history, Infinity datasource), Model Context Protocol, Pydantic, Google Cloud Run, Google Secret Manager, archive.org.

Challenges we ran into

A test suite can be green and have touched nothing. pytest counts a skip as a non-failure, so a suite whose every Grafana test skipped still prints a number with no red in it, and the number is what people read. tests/conftest.py now runs one rule: if GRAFANA_URL and a token are both set, this run asserted a stack is there, so failing to reach it is red rather than skipped. Only a bare clone skips, and it prints a banner naming what it did not prove. Three states, all measured: bare clone 67 passed 11 skipped exit 0, pointed at a hostname with no stack behind it 67 passed 11 errors exit 1, real stack 78 passed 0 skipped exit 0. Eleven tests move from skipped to passing, and the runtime moves with them.

get_annotations answers {"Payload": [...]}, not a list. The live test wrote an annotation, read it back by its own unique tag, and got zero rows. The write had landed; the caller expected a bare list and read every successful query as empty. Only a test that talks to the real endpoint can find that, which is the argument against the mock Grafana that would have agreed with whatever was sent to it.

Absence rendering as success, on the number that decides whether a master clips. in_spec checked the true peak only when a true peak figure existed. Drop peak=true from the filter and ffmpeg stops printing that block, the check is skipped, and the title comes back in spec against a ceiling nobody measured. Worse, the close gate looked only at integrated loudness, so a record could close on a repaired file whose peaks the gain change itself had pushed over the ceiling. Both are now failures with a named reason, and thirteen tests hold it from both sides.

alerting_manage_rules needs an explicit org_id. Without it, the create is refused with org_id is required and must be greater than 0 while dashboards, folders and annotations all succeed, so a stack looks fully writable and still refuses the one write that opens an alert. The tool's JSON schema does not list org_id under required, only mentioning it in a field description, and GRAFANA_ORG_ID in the environment does not help because mcp-grafana reads that for its own configuration while the alerting handler reads the argument.

ffmpeg -nostats silently removes the loudness series. The summary block still prints, so a measurement looks perfect right up until you ask for the shape of the programme. Same on ffmpeg 9.0.1 with ebur128=framelog=verbose, which prints only the summary. The per-100 ms lines come from the default log level, so the command passes neither.

A new rule group evaluates once a minute. A run that creates a rule, repairs the file and updates the rule inside forty seconds never observes the firing state at all: the ruler just reports the final answer. The group interval is set to ten seconds through the provisioning API, still over MCP, which is what makes the transition visible inside one run.

Cloud Run throttles CPU between requests. The first background run on the deployed service sat for eight minutes before its MCP server even started. --no-cpu-throttling fixed it. Separately, Cloud Run answers /healthz itself with Google's own 404 page and never forwards it to the container, while /nope reaches the app and gets the app's 404.

One cold read from archive.org cost the whole fleet. A fresh container asked for The Memphis Belle, got curl exit 22, and ensure_fleet raised on the first failure, so the other seven masters were never fetched and the product had nothing to measure at all. The fetch now retries with a widening pause, deletes whatever a broken transfer left behind rather than measuring it, and scopes a refusal to its own title. /api/status reports how many masters are on disk, so a request that arrives while the 190 MB is still landing is told the fleet is still landing.

Accomplishments that we're proud of

The alert that closes itself, and cannot be closed any other way. Two independent gates: arithmetic over a second ffmpeg pass, and a reviewer that can only withhold. A model with no way to grant closure cannot talk an out-of-spec master into delivery.

The series read-back. A dashboard save returns 200 whether or not the panel carries any data, so the run asks Grafana for the dashboard back and compares 1,201 rows against the ffmpeg measurement to 0.001 LUFS. Altering one sample turns that check red, which is how we know it is a check.

Every capability discovered by trying it. On this stack create_incident is advertised, its plugin is installed and enabled, and a real create fails inside Grafana's own database on a foreign key against a missing Org row. Nothing in the tool list says so. The run routes to a Grafana alert rule instead and prints the refusal verbatim.

The fleet, ranked by error budget burn

Post-conditions, and the query that established each one

What we learned

An accepted request is not a completed operation, and the gap between them is where demos live. Every write in this product is followed by a read that only a landed write could answer, and two of them are polls that wait for a system we do not control to agree with us.

A check that cannot fail is worse than no check, because it occupies the space where a real one would go. The version of that lesson we did not expect was that it applies to the tally at the bottom of a test run as much as to any individual assertion.

What's next for Interlock

Full-length passes rather than declared windows, which is a scheduling problem rather than a measurement one. Writing the series into Grafana Cloud Prometheus once an Access Policy token with metrics:write is in place, so a title's loudness can be queried alongside everything else in the stack. And the second failure class: The Memphis Belle is over the true peak ceiling, which no gain change fixes, and a limiter pass with its own before-and-after measurement is the same loop applied to a different defect.
