Harware Semaphore

•

  Electronics Schematic

Hardware Semaphore

Build with in Arduino IDE, and physical hardware, we build a semaphore were wait in green, blink in yellow and then wait in red, blink a last time in yellow and repeat the cicle

Built With

• arduino
• arduinoide
• easyeda
