Glambulator

Application for exploring the CIDOC Conceptual Reference Model (CRM) and phenomena annotated by it at the instance level

To Do

  • normalize data model
  • make Entity graph informative (!)
  • implement zoom, dragging to facilitate navigation through the potentially expansive Entity graphs
  • add more Sparql endpoints
  • add Sparql queries
  • persist state to local storage
  • add documentation, unit-testing

Run the app locally

  1. Ensure that your environment contains the basic dependency of the project: node.js (using nvm)

  2. Clone this repository via ssh

    git clone git@github.com:michaelnetbiz/glambulator.git


    or https

    git clone https://github.com/michaelnetbiz/glambulator.git

  3. Navigate into the directory

    cd TransitionalCareAnalyticsDashboard/

  4. Confirm whether your current version of node.js matches the project's version (declared in .nvmrc)

  5. Install dependencies

    npm install

  6. Run app locally

    npm start


Application Structure

<div id="root"> <!-- React application mount point-->
  <Provider>
    <MuiThemeProvider>

    </MuiThemeProvider>
  </Provider>

Data Management

The application implements a Redux store to manage state.

Why Redux?

That is to say, why not provide data to React components and their children using component state, implementing some flavor of Facebook's Flux application architecture? Frankly, the appealing thing about React.js development, in the first place, was the unidirectional data flow, which is a core principle of both Redux and Flux/Flux implementations. Two reasons, in the end (curiosity aside).

Local storage

Persisting state to the browser's local storage is simply a matter of serializing the single state object and deserializing it, setting as the initial state at the beginning of the application lifecycle.

Testing

The pure functions encouraged by Redux and middleware like redux-immutable-state-invariant, in conjunction with the componentization afforded by React, makes for pleasant unit-testing. With the exception of the asynchronous action creators used in the entity, referenceModel, and sparqlQuery modules, there is no need for mocking.

Data Model

Within the single state object, the core objects contain data pertaining to the CRM, the SPARQL-querying facility, the instances returned by the SPARQL endpoint, and the status of the various user interface components (e.g., drawer toggled or not, feedback issuing or not). Here is how the application state might look at any given point in time.

{
  common: {
    currentTab: 'entityGraph',
    feedbackAction: '',
    feedbackContent: '',
    isFeedbackIssuing: false,
    loadingColor: '#3949ab',
    isMobile: false,
    isNavDrawerOpen: false,
    isSparqlQueryDrawerOpen: false
  },
  entity: {
    entities: [
      [
        -202467184,
        {
          type: 'uri',
          value: 'http://collection.britishmuseum.org/id/object/23',
          isFocus: false,
          id: -202467184,
          className: 'britishMuseumCollectionObject',
          groupNumber: 0,
          abbreviatedValue: 'id/object/23',
          index: 0,
          x: 517.0668538912479,
          y: 496.24175125267817,
          vy: 15.751936818846984,
          vx: -7.000978332103126
        }
      ]
    ]
    entityGroupFilter: -1,
    entitySelection: {
      type: 'uri',
      value: 'http://collection.britishmuseum.org/id/object/23',
      isFocus: true,
      id: -202467184,
      className: 'britishMuseumCollectionObject',
      groupNumber: 0,
      abbreviatedValue: 'id/object/23'
    }
    isEntityLoading: false,
    statements: [
      [
        40757526,
        {
          subj: {
            type: 'uri',
            value: 'http://collection.britishmuseum.org/id/object/23',
            isFocus: false,
            id: -202467184,
            className: 'britishMuseumCollectionObject',
            groupNumber: 0,
            abbreviatedValue: 'id/object/23',
            index: 0,
            x: 517.0668538912479,
            y: 496.24175125267817,
            vy: 15.751936818846984,
            vx: -7.000978332103126
          },
          pred: {
            type: 'uri',
            value: 'http://erlangen-crm.org/current/P50_has_current_keeper',
            isFocus: false,
            id: -918561899,
            className: 'ontologyResource',
            groupNumber: 2,
            abbreviatedValue: 'current/P50_has_current_keeper',
            index: 3,
            x: 757.2252906268773,
            y: 356.55481201432383,
            vy: 12.156231433422803,
            vx: 7.547420643036565
          },
          obj: {
            type: 'uri',
            value: 'http://collection.britishmuseum.org/id/the-british-museum',
            isFocus: false,
            id: -1279364364,
            className: 'britishMuseumCollectionObject',
            groupNumber: 0,
            abbreviatedValue: 'id/the-british-museum'
          }
        }
      ]
    ]
  }
  referenceModel: {
    isReferenceModelLoading: false,
    resources: [
      {
        id: 'E1_CRM_Entity',
        type: 'rdfs:Class',
        supers: [],
        name: 'CRM Entity',
        description: 'This class comprises all things in the universe of discourse of the CIDOC Conceptual Reference Model. \nIt is an abstract concept providing for three general properties:\n1.\tIdentification by name or appellation, and in particular by a preferred identifier\n2.\tClassification by type, allowing further refinement of the specific subclass an instance belongs to \n3.\tAttachment of free text for the expression of anything not captured by formal properties\nWith the exception of E59 Primitive Value, all other classes within the CRM are directly or indirectly specialisations of E1 CRM Entity. \n'
      }
    ]
    version: '6.2.1'
    sparqlQuery: {
      sparqlQueryDescription: 'Returns twenty instances of E1_CRM_Entity.',
      sparqlQueryExpression: {
        prefix: 'crm: <http://erlangen-crm.org/current/>',
        'select distinct': '?instance',
        where: '{ ?instance a crm:E1_CRM_Entity }',
        filter: false,
        order: false,
        limit: 20
      },
      isSparqlQueryLoading: false,
      sparqlQueryName: 'isa E1_CRM_Entity',
      sparqlQueryResults: [
        [
          -1279364364,
          {
            type: 'uri',
            value: 'http://collection.britishmuseum.org/id/the-british-museum',
            isFocus: false,
            id: -1279364364,
            className: 'britishMuseumCollectionObject',
            groupNumber: 0,
            abbreviatedValue: 'id/the-british-museum'
          }
        ]
      ]
    }
  }
}

State Changes

In keeping with the Redux store pattern, the only ways to change state is by dispatching an action. The actions used to update the data outlined above are listed here.

ActionType Module Description
APPLY_ENTITY_GROUP_FILTER entity
CLEAR_FEEDBACK common
GET_ENTITY entity
GET_ENTITY_FAILURE entity
GET_ENTITY_SUCCESS entity
GET_REFERENCE_MODEL referenceModel
GET_SPARQL_QUERY sparqlQuery
GET_SPARQL_QUERY_FAILURE sparqlQuery
GET_SPARQL_QUERY_SUCCESS sparqlQuery
RECEIVE_ENTITY entity
RECEIVE_REFERENCE_MODEL referenceModel
RECEIVE_SPARQL_QUERY sparqlQuery
SELECT_ENTITY entity
SET_FEEDBACK common
SET_SPARQL_QUERY sparqlQuery
SET_TAB common
TOGGLE_NAV_DRAWER common
TOGGLE_SPARQL_QUERY_DRAWER common
UPDATE_ENTITY_DATA entity

Data Management Utilities

Workflow

Version Control

Adapted from this post.

Iterative feature development on branch develop

  1. Checkout branch develop.

    git checkout develop

  2. Create & checkout branch some-feature from develop to work on some feature.

    git checkout -b some-feature develop

  3. Merge some-feature commits back into develop and delete branch *some-feature.

    git checkout develop
    git merge --no-ff some-feature
    git branch -d some-feature
    git push origin develop


Releasing from branch develop

  1. Checkout branch release-VERSION from develop for finishing touches.

    git checkout -b release-VERSION develop

  2. Merge release-VERSION commits into master to release this next version, and back into develop as well.

    git checkout master
    git merge --no-ff release-VERSION
    git checkout develop
    git merge --no-ff release-VERSION
    git branch -d release-VERSION


Tools and Technologies

  • es6
  • babel
  • webpack
