Gear Guide

Gear Guide is an AI ChatBot that diagnoses vehicle issues using a Neo4j knowledge graph, OpenAI embeddings, and a hybrid retrieval engine for accurate, contextual troubleshooting.

Comment

GearGuide

The application is hosted on GearGuide

Demo link: GearGuide demo

Github Link: https://github.com/Anusha-raju/GearGuidev2.git

Gear Guide: A Graph-Powered AI Chatbot for Smarter Troubleshooting

The Problem:

Modern car owners often face technical issues, whether it's "AC not cooling" or "headlights flickering” but traditional troubleshooting tools and chatbots fall short. They struggle with maintaining context, handling ambiguous symptoms, and offering precise repair instructions. The experience is frustrating: repetitive conversations, generic answers, and no memory of what was said just moments ago.

The Spark:

Our idea for Gear Guide, an AI-powered RAG (Retrieval-Augmented Generation) chatbot, was born out of this gap. We envisioned a smarter support assistant, one that understands vehicle systems, remembers user queries, and guides them through structured, contextual answers. By blending OpenAI’s embeddings with Neo4j’s graph-based knowledge and a hybrid retrieval strategy, we designed a chatbot that behaves less like a script and more like a skilled mechanic’s assistant.

How It Works: Under the Hood of Gear Guide

Gear Guide combines the best of semantic search and knowledge graphs:

  1. A Rich, Structured Knowledge Base We modeled technical car data as a graph in Neo4j, organizing relationships between components, symptoms, procedures, and problems. For example:

    a. "AC not cooling" connects to symptoms like "low airflow" and tests like "compressor pressure check".

    b. "Remote key not working" links to "keyless entry malfunction", a common user concern.

  2. Data Ingestion via LLM (Large Language Models) Manuals and troubleshooting documents were converted into structured XML using a custom PDF-to-Graph pipeline powered by GPT. Tags like <symptom>, <procedure>, and <test> were extracted to feed into the Neo4j graph—no manual curation needed.

  3. Hybrid Retrieval (Dense + Sparse)

    a. Dense Retrieval uses OpenAI’s embeddings + Neo4j vector index for semantic matches.

    b. Sparse Retrieval uses full-text Lucene search to capture exact keyword hits.

    c. A Hybrid Strategy reranks results using a weighted score (hybrid_score = α * dense + (1-α) * sparse), ensuring the best of both worlds: relevance and accuracy.

  4. Multi-Turn Conversations Every query goes through rephrasing and context injection, allowing the system to maintain continuity in chat sessions—an often-missing feature in traditional bots.

  5. Interactive UI The frontend is built with Flask, providing a responsive interface where users can ask natural questions like:

    a. “Why isn’t my AC working?”

    b. “How do I replace the bumper on a Yaris?”

    c. “What could cause dim headlights after engine start?”

Why It Matters

Gear Guide isn’t just a chatbot—it’s a structured AI assistant that thinks in graphs.

By linking symptoms, problems, and test procedures with real-world semantics, we provide users with a guided diagnostic experience. Our hybrid search approach outperforms both keyword-based and purely semantic systems, delivering answers that are contextually rich and technically grounded.

Key Impact

  • Smarter Repairs: Faster and more accurate troubleshooting for drivers and technicians

  • Context-Aware AI: True multi-turn memory and relevance optimization

  • Hybrid Retrieval: Combines the power of semantic understanding and exact match precision

  • Graph-Powered Insights: Every problem is navigated through connected components and causes

Full Technical Document

Graph Schema Overview

Schema Overview

Graph Schema Overview

Node Types

Node Label Description
ProductGroup Vehicle categories
Manufacturer Car maker (e.g., Toyota)
Model Car model (e.g., Yaris)
Component Part of the vehicle
Problem Issues faced
Symptom Observable signs
Procedures Repair/installation steps
BasicInfo General car information
SubComponent Detailed internal components
AdditionalInfo Notes, warnings, extra data
SuspectArea Potential faulty regions
TestProcedures Diagnostic steps

🔗 Relationships

Relationship Name Description
HAS_MODEL ProductGroup → Model
MANUFACTURED_BY Model → Manufacturer
HAS_COMPONENT Model → Component
HAS_PROCEDURES Component → Procedures
HAS_SYMPTOM Problem → Symptom
HAS_SUBPROBLEM Problem → Sub-problem (hierarchical)
HAS_ADDITIONALINFO Component/Problem → AdditionalInfo
HAS_SUSPECTAREA Problem → SuspectArea
HAS_BASICINFO Component → BasicInfo
HAS_SUBCOMPONENT Component → SubComponent
HAS_TESTPROCEDURES Component → TestProcedures

PDF → Structured XML via LLM

Script: pdf_extraction.py

  • Extracts raw text from manuals
  • Breaks long text into chunks
  • Uses GPT to output structured data with tags like:
  `<problem>ac not cooling</problem>`
  `<symptom>weak airflow</symptom>`
  `<test><name>compressor test</name><procedure>Check pressure</procedure></test>`

- Tags are flexible; non-standard tags are stored under `<additional_info>`

Data Ingestion Flow

Script Logic

Function: parse_and_insert_data(xml_content, component_name)

  • Cleans XML from LLM output
  • Maps each XML tag to Neo4j label via tag_to_label_map
  • Creates and links graph nodes using Cypher queries
  • Handles nested problems and long lists efficiently
  • Uses APOC for conditional logic in Cypher (dynamic merging)

Embedding-Based Dense Retrieval

Function: get_openai_embedding

  • Embedding Model: text-embedding-3-small
  • Converts user queries into dense vectors

Function: vector_search(query_vector, node_label, top_k=10, threshold=0.7)

  • Vector Index Name: vectorIndex_<NodeLabel>
  • Cypher Syntax: cypher CALL db.index.vector.queryNodes($index_name, $top_k, $query_vector)

Sparse Retrieval

Function: sparse_search(user_query, node_label)
Uses full-text search index:

CALL db.index.fulltext.queryNodes('search_<Label>', $query) YIELD node, score
RETURN node.name, score

Hybrid Retriever

Function: Use ThreadPoolExecutor to parallelize vector and full-text search
Combines dense and sparse scores:

hybrid_score = alpha * dense_score + (1 - alpha) * sparse_score
  • Create retrieve_data() to unify both retrieval strategies
  • Normalize scores before combining
  • Filter by top-k if needed
  • Merge and deduplicate results by node name

User Flow Diagram

[User Query]
     ↓
[Rephrasing with LLM (if chat history exists)]
     ↓
[Embedding Generation using OpenAI]
     ↓
┌────────────────────┐       ┌────────────────────┐
│ Dense Search        │     │ Sparse Search       │
│ (Neo4j Vector Index)│     │ (Fulltext Lucene)   │
└──────────┬──────────┘     └──────────┬──────────┘
           ↓                           ↓
     [Hybrid Merge & Rerank Scores (alpha-weighted)]
                       ↓
         [Deduplication & Top-K Selection]
                       ↓
       [Graph Expansion (Related Nodes)]
                       ↓
         [Final LLM Response Generation]

Sample User Queries & Results

User Query Top Match Node Node Type Score
"AC not working properly" "ac system not cooling" Problem 0.89
"Car remote doesn't lock" "keyless entry malfunction" Problem 0.86
"Headlights flickering at night" "check headlamp fuse" Procedures 0.81
"Steering makes noise when turning" "steering fluid low" Symptom 0.83
"What's the cause of engine overheating?" "radiator coolant leak" SuspectArea 0.84

Visual Graph Snapshot – Example Traversal Path

Query: "AC not cooling"

AC Graph Schema Overview

Traversal Path (Graph View):

(:Component {name: "air conditioning"})
   └──[:HAS_PROBLEM]──> (:Problem {name: "ac not cooling"})
       └──[:HAS_SYMPTOM]──> (:Symptom {name: "low airflow"})
       └──[:HAS_PROCEDURES]──> (:Procedures {name: "check compressor pressure"})

Comparative Outcomes – Dense vs Sparse vs Hybrid

Query: "Remote key not working"

Retrieval Mode Top Match Type Score Notes
Sparse "key" → "lock" → "battery" Problem 0.65 Keyword match, misses context
Dense "keyless entry not responding" Problem 0.86 Captures intent, loses exact token
Hybrid "keyless entry malfunction" Problem 0.92 Best of both, exact + semantic

Conclusion: Hybrid retrieval improved both relevance and clarity. It correctly inferred "remote key" refers to "keyless entry".

Real-World Query Examples (for Demo/Docs)

Query Expected Top Match Node Type Why it's relatable
"AC not working" "ac system not cooling" Problem Common summer issue
"Car won’t lock with remote" "keyless entry malfunction" Problem Frequent user complaint
"Headlights dim after engine starts" "battery voltage drop" Symptom Electrical fault diagnosis
"Steering hard to turn" "low power steering fluid" SuspectArea Linked to hydraulic issue
"How to remove bumper?" "bumper removal procedure" Procedures Practical DIY fix

Tip: Capture real user-like phrasing to test the robustness of your retrieval system.

Environment Configuration

Key Purpose
NEO4J_URI Neo4j DB connection URI
NEO4J_USERNAME Neo4j DB Username
NEO4J_PASSWORD Neo4j DB Password
OPENAI_API_KEY LLM + Embedding access
EMBEDDING_MODEL OpenAI model (default: text-embedding-3-small)
model Chat model (default: gpt-4o)
alpha Weight for hybrid scoring
top_k Result cutoff
threshold Similarity threshold
SECRET_KEY Secret key for the sql database
SQLALCHEMY_DATABASE_URI Database connection server

Function Reference

Function Name Description
extract_pdf_content Read PDF into plain text
structure_content_with_llm Generate structured XML tags
parse_and_insert_data Create nodes and relationships in Neo4j
get_openai_embedding Generate dense vector from text
vector_search Perform ANN vector search
fulltext_search Run Lucene query on text fields
hybrid_search Merge dense + sparse results
process_top_nodes Expand retrieved node context
final_call Generate final LLM response
rag_advisor Full pipeline: input → answer

Future Vision

Gear Guide began as a proof-of-concept for smarter troubleshooting using RAG and graph-based reasoning, but its potential goes far beyond automotive diagnostics.
Here's where we see it heading:

  1. Multi-Domain Diagnostic Assistant

    Extend beyond vehicles into other verticals where structured troubleshooting is critical:

    a. Consumer electronics (e.g., phone won't charge → battery port → test cable → reset)

    b. Medical equipment diagnostics for technicians

    c. Smart home systems (e.g., thermostat issues, smart lock malfunctions)

  2. Continual Knowledge Ingestion

    Automate ingestion of new manuals, guides, and repair logs in real-time using:

    a. Fine-tuned LLMs for multi-lingual manuals

    b. Auto-tagging pipelines with confidence thresholds

    c. Crowdsourced updates from technician feedback

  3. Voice-Enabled Mobile Companion

    Build a mobile app where users can:

    a. Speak their car issues out loud ("my engine's rattling at startup")

    b. Get step-by-step procedures

    c. Use AR overlays (e.g., guide you to open the hood, check the dipstick)

  4. Closed-Loop Learning System

    a. Track which troubleshooting paths led to successful resolutions

    b. Reinforce the knowledge graph based on real-world usage

    c. Use reinforcement learning or fine-tuning to improve LLM grounding

  5. B2B Integration with Repair Shops

    Partner with:

    a. Automotive repair shops for technician-facing AI tools

    b. Manufacturers for embedding Gear Guide in owner apps, onboard systems, or support portals.

Contributors:

Anusha Umashankar | LinkedIn | Email: anusha.u.raju@gmail.com

Dinesh Karnati | LinkedIn | Email: dineshkarnati510@gmail.com
