DNS3.0: Trustless DNS with Ethereum, Local DNS and Radical Markets
This DNS3.0 "hackathon" project develops a piece of a DNS 3.0 stack, aiming for trustless decentralized DNS systems integrating with Handshake's decentralized TLD.
DNS is managed with Zone files like this one, typically by a web master updating DNS records in a website UI in Godaddy / Cloudflare / Google / ... DNS Manager, so that when users visit a name-friendly url like "http://www.eth.hacker" their browser will map them to an IP
;; eth.hacker zone entries ;; A Records www.eth.hacker. 3600 IN A 22.214.171.124 ganache.eth.hacker. 1 IN A 126.96.36.199 remix.eth.hacker. 1 IN A 188.8.131.52
Behind the scenes, when users browsers ask for
www.eth.hacker there is:
- a user's trusted DNS provider (e.g. 184.108.40.206 run by Google, or your local monopolist ISP) that figures out the name server for
eth.hackerand asks that name server to look up the value for
- a name server for
eth.hackerhosted by a trusted Zone file database editor like Godaddy or Google DNS
- a root "Top level domain" (or "TLD") server (e.g. ".com, .edu, .org"), which have historically been managed with a dozen or so organizations (see http://www.root-servers.org/)
People learn about (1) when setting up their new Internet connection, learn about (2) when setting up a new web site, but almost no one is aware of (3). However, all of this comes together in a few hundred milliseconds.
Can the trusted systems that manage (1) DNS lookup (2) database zone records (3) TLD root servers be replaced with completely trustless DNS protocols? We believe the answer is YES.
Recently, the lowest level (3) has been developed into a new blockchain protocol by handshake.org, where new TLDs (e.g.
.hacker) can be bought and queries resolved in a trustless way, replacing 12-13 truste parties. Before the rise of Ethereum, a special purpose blockchain named
Namecoin built a special purpose blockchain to handle (1) + (2), but it never really took off. This DNS3 project is a prototype that aims to show how (1) name look up + (2) zone files of domains can managed in a trustless way with a local DNS server that connects to a DNS3.sol Smart contract that keeps the Zone file hashes in a decentralized storage backend (IPFS).
Demonstration of DNS3
Part 1: DNS3.sol Ethereum Smart Contract
The main idea is that core DNS zone data are kept in an Ethereum Smart Contract like
DNS3.sol (View on Rinkeby)
Domain owners for new TLDs like
.hacker will manage their DNS entries by:
[txn #1] registering their domain with
registerDomain(string _domain), where a domain
eth.hackeris represented on Ethereum with a domainHash like:
[txn #2] updating the zone record for the
submitZone(bytes ipfsHashByte, bytes32 domainHash)
where the zone file hash
QmXThgG1gUnfywM4e9QpEYDkBZNJwSbpPogJjXtewVgYmi is represented in a 34-byte
In this model, zone files are held in decentralized storage (IPFS), where a zone file is uniquely retrievable and verifiable by their zone file hash such as this one:
When someone adds a new record like:
dev.eth.hacker. 3600 IN A 220.127.116.11
the owner of
eth.hacker updates the zone hash entry in this contract.
Part 2: Local DNS resolution
In DNS3.0, when devices resolve DNS entries like
dev.eth.hacker, instead of resolving to 18.104.22.168 Trusted server, their local resolver will:
- read the latest zone file 32-byte hash with
getZone(bytes32 domainHash)by hashing
- do a HTTP GET fetch to get the ZONE file from decentralized storage:
- from the zone in the HTTP Response, get the
We demonstrate a proof-of-concept showing that a local DNS server (
github.com/miekg/dns) can do local domain resolution:
$ go test -run DNSRequest DNS3 Request: dev.eth.hacker tld: hacker domain: eth.hacker domainHash: 0xb63f160a960a1663c5cec1d7d02e67a44d368affd1d42be3b3554c34fd2dea4b DNS3.sol Call: getZone(0xb63f160a960a1663c5cec1d7d02e67a44d368affd1d42be3b3554c34fd2dea4b) ipfsHash: 87879aa6968d1f21be72500bbeea130b1003efca205101364a77086b6abbb7d5 => QmXThgG1gUnfywM4e9QpEYDkBZNJwSbpPogJjXtewVgYmi IPFS Lookup: https://cloudflare-ipfs.com/ipfs/QmXThgG1gUnfywM4e9QpEYDkBZNJwSbpPogJjXtewVgYmi... FOUND DNS3 Result: 22.214.171.124 PASS ok github.com/wolkdb/dns3/dns3 1.013s
Given a DNS3 Request of
dev.eth.hacker, the above test computes the domain
getZone(bytes32 domainHash) with the Keccak hash of
eth.hacker and gets back the latest zone file hash
Then it does a HTTP GET to IPFS to get the latest Zone file, and then retrieves the latest value
When everyone runs local DNS Servers, we get totally trustless DNS!
... One more thing: Radical Markets
We believe this trustless DNS3.0 approach can be adapted for new TLDs managed entirely with Handshake. To reduce domain squatting (common to NameCoin, ENS, and the current Domain Name Registration system), we propose to adapt a "Radical Markets" technique proposed by Weyl and Posner to our DNS3.sol smart contract:
- domain name registrants specify a sale price when they register. When they do so, they commit to paying a fixed percentage of that sale price every 1MM blocks. Otherwise, anyone can pay that sale price and secure the rights to the domain. A grace period of 7 days is offered to ensure that a transition can be smooth, or for the current owner to increase his sale price to override the transfer, but the override cost must be at least 10x higher.
- Example: Alice purchases a new domain
dns3.hackerfor a price of .1 ETH but sets her sale price to 10ETH. Bob sees
dns3.hackerand submits a
acquireDomain(bytes32 domainHash)payable transaction for 10ETH to get it. If Alice does nothing, after 7 days, Bob (or anyone) can finalize the purchase by calling
finalizeDomain(bytes32 domainHash), which transfers the funds to Alice. If Alice pays 100ETH to keep the
dns3.hackerdomain, she (and only she) can call
challengePurchase(bytes32 domainHash)This technique incentivizes domain owners to set their sale price to be within an order of magnitude of what they value it at. If Alice rushes to buy 80,000 English word domains for .01 ETH each and sets a sale price of 10 ETH thinking she'll make killing, she must pay "taxes" based on the 1 ETH. On the other hand, if some old company comes by and wishes to pay 10 ETH for it, they may do so, but Alice does not benefit massively for having sat on it.
