COBRA GPU Kernel

#TEAMCOBRAFORTHEWIN
#TEAMCOBRA 9.19x MEDIAN SPEED UP

Inspiration

Transformer inference is dominated by dozens of small, sequential PyTorch dispatches — QKV projections, attention, softmax, output projection, LayerNorm — each launched as its own CUDA kernel with its own overhead. The TikTok TechJam GPU Kernel Challenge asked participants to take a fixed transformer layer and reimplement it as custom GPU kernels that stay numerically close to the PyTorch reference (rel error < 0.02, abs error < 0.002) while running dramatically faster, across shapes ranging from tiny batches to a sequence length of 100,000 tokens that doesn't even fit in memory in its naive form.

What it does

This project — Blackwell Transformer Kernel (sm_120) — is a fused Triton implementation of the challenge's transformer layer, tuned and measured on an NVIDIA RTX 5060 Ti (Blackwell, sm_120, 16 GB). Four Triton kernels replace the reference's ~29 PyTorch dispatches per layer, the forward pass runs as a single CUDA-graph replay wherever that's a net win, and for the one shape whose activations physically exceed VRAM, inputs are streamed in batch chunks sized dynamically from the device's actual free memory.

Headline results:

Median 9.19x speedup over the 13 test shapes with a runnable PyTorch reference (geometric mean 8.67x, arithmetic mean 11.23x)
All 14 shapes execute correctly with zero failing elements, worst-case max_abs error of 1.35e-03 against a 2e-3 gate
Best single-shape speedup: 33.34x (B64 d128 H4 S1024); smallest: 2.87x
The 14th shape — B=32, d=1024, H=16, S=100,000 — cannot run on any hardware under the naive reference implementation, since materializing the attention score matrix would require 19,073 GB. This implementation streams it to completion in 37.67 s at 36.9 TFLOP/s (73% of the card's measured fp16 peak), validated bit-exact against a memory-safe custom oracle, with per-sequence cost holding steady (1.14–1.18 s) across a 16x batch range.

How we built it

The kernel bodies (QKV+attention fusion, LayerNorm-in-epilogue fusion, fp32-store GEMM, CUDA-graph capture) originate from the upstream COBRA GPU kernel project, tuned on an RTX 3050 (sm_86) under Windows. This branch's contribution — roughly 1,900 lines — re-derives every hardware-specific tuning constant against direct measurement on Blackwell sm_120 rather than assuming portability, and adds capability the original didn't have:

Shape 14 (the impossible one): host-streamed batch chunking sized from torch.cuda.mem_get_info(), with halve-on-OOM fallback, plus a memory-safe reference oracle (tools/reference_chunked.py) proven torch.equal-identical to the stock baseline across 16 configurations.
Precision policy fix: discovered that a float32 floor below d_model=64 was silently disabling the Triton GEMM and falling back to cuBLAS TF32 (same 10 mantissa bits as fp16, without the fp32-store accuracy correction). Removing it yielded a 1.34x speedup and better accuracy, confirmed over a 360-trial campaign.
Fusion gate correction: the QKV+attention fusion requires BM >= S (tile height tied to sequence length). Added a lower seq_len bound after measuring the fused path running 1.13x slower at S=32.
Attention tile re-derivation: re-tuned against the card's 36 SMs — head_dim=64 tiling gave a 1.22x gain, and the head_dim gate was raised from 128 to 256 after measuring the Triton kernel beating FlashAttention-2 by 1.11x in that regime.
Measurement infrastructure: 12 standalone harnesses under tools/ — an analytic shared-memory/occupancy pruner for tile search, in-graph timing, SDPA backend comparison, CUDA-graph gate A/B testing, precision campaigns, and per-kernel timing breakdowns.

Every tuning decision above was reached empirically, not assumed — including nine rejected approaches documented in report/measurements/.

Development tools, APIs, libraries & frameworks

Language/runtime: Python 3.14.4
Core libraries: PyTorch 2.11.0 (cu128), Triton 3.6.0 — every kernel is JIT-compiled at first use, no separate compiler toolchain required
GPU stack: CUDA driver 595.84, targeting sm_120 (Blackwell)
No external APIs — this is a pure GPU-kernel / systems-performance project; there's no model inference API or web service involved, just PyTorch, Triton, and the hardware
Custom tooling: an internal suite of 12 Python measurement harnesses (tools/sweep.py, tools/validate.py, tools/reference_chunked.py, tools/graph_gate.py, tools/sdpa_backend.py, tools/diag_small.py, tools/breakdown.py, tools/time_case14.py, etc.) built specifically for this project to drive tile search, correctness validation, and precision/timing campaigns

Datasets and assets used

No external dataset was needed — the "data" here is the challenge's own synthetic input-shape matrix (14 combinations of batch size, hidden dim, head count, and sequence length, up to B=32, d=1024, H=16, S=100,000), generated at test time, plus a self-built, torch.equal-verified memory-safe reference oracle used to validate correctness on the one shape too large for the stock PyTorch baseline to run at all.

Challenges we ran into

The reference itself is an unreliable ground truth for speed: its own timings swing up to 2.63x run-to-run on several shapes, while this implementation's timings hold within 1.4%. Every reported speedup is corroborated by at least two independent sweeps to compensate.
No usable kernel-level profiler was available: CUPTI failed with CUPTI_ERROR_INVALID_DEVICE and Nsight required root privileges unavailable in the environment, so occupancy had to be modelled via an analytic pruner rather than measured directly — every model-ranked configuration was then re-confirmed with direct timing before being adopted.
Shape 14 is a genuine hardware wall, not just a slow case: the naive reference would need to materialize a 19,073 GB attention score tensor. Solving it required rethinking the problem as a streaming/chunking problem rather than a kernel-fusion problem, sized dynamically off real-time free VRAM.
A silent precision bug: the float32 fallback path for small d_model was quietly costing both speed and accuracy — an easy thing to miss without a systematic 360-trial precision campaign.

Accomplishments that we're proud of

A median 9.19x speedup with zero failing elements across all 14 shapes
Making an "unrunnable" shape (S=100,000) not just execute, but execute at 73% of the card's measured fp16 peak
Every hardware-specific constant re-derived from first-principles measurement on new hardware (sm_120) rather than inherited assumptions from the sm_86 original
Transparent reporting of limitations and nine explicitly rejected optimization approaches, rather than only showing what worked

What we learned

Porting a kernel between GPU architectures isn't just "does it run" — every tile size, fusion gate, and precision fallback that was correct on sm_86 needed to be re-measured, and two of them were actively wrong on sm_120. Median-and-mean speedup numbers can hide unstable ground truth; when the reference implementation itself has multi-x run-to-run variance, correctness and reproducibility require independent oracles and repeated sweeps, not a single benchmark run.

What's next for the project

Reclaim the up-to-2.39x of unclaimed bandwidth headroom on bandwidth-bound shapes once a precision approach is found that doesn't erode the accuracy margin under input-scale stress
Get real kernel-level profiling working (root/Nsight access) to replace the analytic occupancy model with direct measurement
Re-measure Case 6, which currently carries a pre-change timestamp due to VRAM contention from an unrelated process
