Secundus Dermis

An AI-powered fashion storefront built as a customer support agent playground. The fictional brand is a prop — the real subject is demonstrating how a conversational AI agent handles the full surface area of e-commerce support: product discovery, visual search, editorial content, and multi-turn dialogue.

The site is also designed as a target environment for external AI agents. Agents such as NanoClaw and OpenClaw can connect via WebSocket, read a machine-readable manifest, and autonomously drive browsing, search, and support scenarios for automated evaluation. See AGENT_WEBSOCKET_PLAN.md.

Quick Start

Prerequisites

Tool	Version
Python	3.11+
Node.js	18+
uv	latest (`pip install uv`)
Gemini API key	aistudio.google.com
Kaggle API token	kaggle.com/settings

Backend

cd backend
cp .env.example .env          # fill in GEMINI_API_KEY, KAGGLE_API_TOKEN
uv sync                       # install dependencies
uv run python api.py          # starts on http://localhost:8000

The DeepFashion Multimodal dataset (~650 MB, 12,278 items) downloads automatically on first run via the Kaggle API if data/labels_front.csv is absent. Interactive API docs at http://localhost:8000/docs.

Frontend

cd frontend
npm install
npm run dev                   # starts on http://localhost:5173

The Vite dev server proxies /api/* → localhost:8000.

Environment Variables

# backend/.env
GEMINI_API_KEY=...                               # required — agent LLM + VLM image search
KAGGLE_API_TOKEN=KGAT_...                        # required — dataset auto-download
ADMIN_KEY=change-me                              # protects POST /journal
AGENT_MODEL=gemini-3.1-pro-preview-customtools
VLM_MODEL=gemini-3.1-pro-preview
IMAGES_DIR=./data/selected_images
JOURNAL_DIR=./journal

Architecture

┌──────────────────────────────────────────────────────────┐
│  Browser — React + Vite SPA                              │
│                                                          │
│  /           About — what this project is                │
│  /shop       Infinite-scroll catalog + sidebar filters   │
│  /product/:id  Product detail                            │
│  /blog       Editorial journal                           │
│  ChatWidget  Floating AI chat, persists across pages     │
│  Header      Navbar with live AI-controlled search bar   │
└────────────────────────┬─────────────────────────────────┘
                         │  REST  (Vite proxy → :8000)
┌────────────────────────▼─────────────────────────────────┐
│  FastAPI  (backend/api.py)                               │
│                                                          │
│  /chat ────── Google ADK Runner ──── Gemini LLM          │
│                     │                                    │
│               search_by_keywords ←── in-memory catalog  │
│               search_journal     ←── markdown files      │
│               get_catalog_stats                          │
│               get_product_categories                     │
│                                                          │
│  /search/image ── Gemini VLM → keywords → keyword_search │
│                              └─ colour histogram re-rank │
│                                                          │
│  /catalog/*  ── pure in-memory filtering (zero API cost) │
│  /journal/*  ── markdown files served as JSON            │
└──────────────────────────────────────────────────────────┘

Text search flow

User message → ADK Runner → Gemini LLM
                                │
              calls search_by_keywords(
                keywords="floral dress",
                gender="WOMEN",
                category="Dresses"
              )
                                │
              in-memory keyword scan of 12,278 descriptions
                                │
              LLM composes reply with product list
                                │
        ← reply + products + filter{ gender, category, query }
                                │
        ChatWidget mirrors filter into ShopContext
        → sidebar highlights Women's + Dresses
        → navbar search populates
        → shop grid filters to match

Image search flow

Uploaded image
  Step 1 — Gemini VLM → "dress, floral, blue, cotton, casual"   PRIMARY SIGNAL
  Step 2 — keyword_search() for each VLM term → ~200 candidates  PRIMARY RETRIEVAL
  Step 3 — colour histogram cosine similarity → re-rank           VISUAL ORDERING
  Return top N sorted by visual similarity

The histogram only orders what keyword search already found — it never retrieves on its own.

Tech Stack Decisions

Layer	Choice	Why
Agent framework	Google ADK (`google-adk`)	Native Gemini tool-calling; `InMemorySessionService` maintains multi-turn context; `Runner` handles the full conversation loop with zero boilerplate
LLM / VLM	Gemini (`gemini-3.1-pro-preview-customtools`)	Function-calling for agent tools; same API key for both chat agent and image description — single dependency, single quota
Product search	In-memory `str in str` keyword scan	12k descriptions fit in RAM; sub-millisecond queries; zero API cost per search — ideal for a high-query demo
Image similarity	96-dim RGB histogram + cosine similarity	No model inference per query; computed once per image and cached lazily; sufficient colour-based visual ranking for a demo
API	FastAPI	Async, Pydantic validation, OpenAPI auto-docs, `UploadFile` for image handling
Frontend	React + Vite + TypeScript	HMR for fast iteration; React Router SPA preserves the chat widget across page navigations without remounting; TypeScript catches API contract mismatches early
Global state	React Context (`ShopContext`)	Sidebar filters and search query shared across all routes — lets the AI chat widget update the shop grid and navbar search without prop drilling
Routing	React Router nested routes + `<Outlet>`	`ShopLayout` defines the sidebar once; `/shop` and `/product/:id` are nested inside it — sidebar never unmounts or re-renders on navigation
Styling	Plain CSS modules per component	Full control over the editorial boutique aesthetic; no framework purge config; variables in `variables.css` for theming
Dataset	DeepFashion Multimodal (Kaggle)	12,278 labelled images with captions across 16 categories for MEN + WOMEN; auto-downloaded via `KAGGLE_API_TOKEN` on first server start
Journal	Markdown + YAML frontmatter	Version-controlled, human-editable, agent-searchable; new posts via `POST /journal` or the `/blog/new` UI

Agent API Reference

Base URL: http://localhost:8000 All bodies are JSON. Interactive docs at /docs.

`POST /chat`

Conversational agent. Routes through Google ADK, calls tools as needed, returns grounded reply.

Request

{
  "message": "Show me women's dresses under $80",
  "history": [
    { "role": "user",      "content": "Hi" },
    { "role": "assistant", "content": "Hello! How can I help you today?" }
  ],
  "session_id": "550e8400-e29b-41d4-a716-446655440000"
}

Field	Type	Required	Notes
`message`	string	✓	The user's message
`history`	array	—	Recent turns `{ role, content }` for context. The ADK session also maintains server-side history independently.
`session_id`	string	—	UUID identifying the conversation. Defaults to `"default"`. Use a stable per-user UUID for real context persistence.

Response

{
  "reply": "I found 6 dresses for you! Here are some highlights...",
  "products": [
    {
      "product_id": "id_00001234",
      "product_name": "Women's Floral Cotton Dress",
      "description": "A light floral cotton dress with short sleeves...",
      "gender": "WOMEN",
      "category": "Dresses",
      "price": 64.99,
      "similarity": 0.0,
      "image_url": "/images/WOMEN-Dresses-id_00001234-01_1_front.jpg"
    }
  ],
  "intent": "text_search",
  "filter": {
    "gender": "WOMEN",
    "category": "Dresses",
    "query": "floral"
  }
}

Field	Type	Description
`reply`	string	Markdown-formatted agent response
`products`	array	Products retrieved by the agent's `search_by_keywords` tool call. Empty for chitchat.
`intent`	`"text_search"` \	`"chitchat"`
`filter`	object \	null

Agent tools:

Tool	Signature	Description
`search_by_keywords`	`(keywords, gender?, category?, max_price?, n_results?)`	Primary product retrieval. Called for all product queries.
`get_catalog_stats`	`()`	Total product count, all categories, all genders.
`get_product_categories`	`()`	Categories grouped by gender.
`search_journal`	`(query)`	Searches editorial articles. Returns title, excerpt, and markdown link `/blog/{slug}`.

`POST /search/text`

Direct keyword search, bypassing the conversational agent. Useful for programmatic or evaluation use.

Request

{
  "query": "leather jacket",
  "n_results": 8,
  "gender": "MEN",
  "category": "Jackets_Vests",
  "max_price": 150.0
}

Response

{
  "results": [ /* Product objects */ ],
  "query": "leather jacket",
  "total": 4
}

`POST /search/image`

Find visually similar products by uploading a photo.

Request — multipart/form-data

Field	Type	Description
`file`	file	JPEG, PNG, or WebP
`n_results`	int	Max results (default 8)
`gender`	string	Optional filter
`category`	string	Optional filter

curl -X POST http://localhost:8000/search/image \
  -F "file=@jacket.jpg" \
  -F "n_results=6"

Response

{
  "results": [ /* Product objects with similarity scores */ ],
  "query": "[image: jacket.jpg] → jacket, leather, brown, casual",
  "total": 6
}

`GET /catalog/browse`

Paginated catalog with filtering. Zero API cost.

Param	Type	Description
`offset`	int	Pagination offset (default 0)
`limit`	int	Page size, max 48 (default 24)
`gender`	string	`"MEN"` or `"WOMEN"`
`category`	string	Exact category name
`q`	string	Keyword filter on name + description

Response

{ "products": [...], "offset": 0, "limit": 24, "total": 347 }

`GET /catalog/product/{product_id}`

Single product by ID.

`GET /catalog/stats`

{
  "total_products": 12278,
  "categories": ["Blouses_Shirts", "Cardigans", "Denim", "..."],
  "genders": ["MEN", "WOMEN"]
}

`GET /journal`

List all posts (no body). Params: category, featured=true.

`GET /journal/{slug}`

Full post including markdown body.

`POST /journal`

Publish a new post. Requires X-Admin-Key header.

curl -X POST http://localhost:8000/journal \
  -H "Content-Type: application/json" \
  -H "X-Admin-Key: your-admin-key" \
  -d '{
    "title": "The Case for Natural Fabrics",
    "excerpt": "Why linen and cotton outperform synthetics year-round.",
    "author": "Editorial",
    "date": "2026-03-28",
    "read_time": "4 min",
    "category": "Style",
    "tags": ["fabric", "basics"],
    "featured": false,
    "image": "",
    "body": "# The Case for Natural Fabrics\n\n..."
  }'

`GET /health`

{ "status": "healthy", "catalog_size": 12278, "search_mode": "keyword + VLM histogram" }

Categories Reference

Men's: Tees_Tanks · Shirts_Polos · Sweaters · Sweatshirts_Hoodies · Suiting · Denim · Pants · Shorts · Jackets_Vests

Women's: Tees_Tanks · Graphic_Tees · Blouses_Shirts · Cardigans · Denim · Pants · Shorts · Skirts · Leggings · Dresses · Rompers_Jumpsuits · Jackets_Coats

Project Structure

SecundusDermis/
│
├── backend/
│   ├── api.py                    # FastAPI app — all endpoints
│   ├── download_data.py          # Kaggle dataset auto-download
│   ├── agent/
│   │   ├── agent.py              # ADK Agent + system prompt
│   │   └── tools.py              # search_by_keywords, search_journal, stats
│   ├── journal/                  # Markdown editorial articles
│   ├── data/                     # Downloaded dataset (gitignored)
│   └── pyproject.toml
│
├── frontend/
│   ├── src/
│   │   ├── main.tsx              # App root — Router, ShopProvider, ShopLayout
│   │   ├── lib/
│   │   │   └── shop-context.tsx  # Global filter + search state (React Context)
│   │   ├── components/
│   │   │   ├── Header.tsx        # Navbar — live AI-controlled search input
│   │   │   ├── ShopSidebar.tsx   # Persistent filter sidebar (defined once in ShopLayout)
│   │   │   ├── ChatWidget.tsx    # Floating AI chat — mirrors filters to sidebar
│   │   │   └── Footer.tsx
│   │   ├── pages/
│   │   │   ├── About.tsx         # Root — describes the AI playground
│   │   │   ├── Shop.tsx          # Infinite-scroll product grid
│   │   │   ├── Product.tsx       # Product detail
│   │   │   ├── Blog.tsx / BlogPost.tsx / NewBlog.tsx
│   │   │   └── FAQ.tsx / Contact.tsx
│   │   ├── services/
│   │   │   └── fashionApi.ts     # Typed API client
│   │   └── styles/               # Per-component CSS
│   └── vite.config.ts
│
├── AGENT_WEBSOCKET_PLAN.md       # WebSocket agent integration design
├── IMAGE_SEARCH_PLAN.md          # Image search architecture + roadmap
├── SESSION_PLAN.md               # Session persistence roadmap
└── NEXT_STEPS.md                 # Overall project roadmap

No Real Commerce

No products can be purchased. No orders are placed. No personal data is stored. This is a technical demonstration of AI-assisted customer support patterns.

Dataset: DeepFashion Multimodal by silverstone1903 on Kaggle — 12,278 items, MEN + WOMEN, 16 categories. AI: Google Gemini via Google ADK.
