BrailleVision

BrailleVision turns physical Braille on paper into English text you can read or hear. Use your phone or webcam to scan embossed or printed dots, no need to copy Unicode Braille characters (⠓⠑⠇⠇⠕) from a screen.

The project combines computer vision (finding and grouping dots), machine learning (recognizing single letters), and a simple web interface with optional read-aloud.

Live app: braillevision.onrender.com/app/

About

Braille matters for independence and literacy, but many family members, teachers, and coworkers do not read it fluently. BrailleVision is meant to help in everyday situations: checking a label, following along in a classroom, or understanding a note without a dedicated human translator every time.

It is an assistive tool, not a replacement for skilled Braille readers or formal accessibility review.

Features

Camera scanning — live preview, single capture, or continuous live scan
Image upload — one file or a batch of images
Physical dot detection — OpenCV finds round blobs and groups them into standard 6-dot cells
Letter recognition — trained classifier (models/braille_classifier.pkl, ~99% on held-out practice data)
Word and line decoding — geometric pattern matching when the camera sees multiple cells
Text-to-speech — optional voice guidance and read-aloud in the browser
Accessible UI — high contrast, large controls, screen-reader-friendly live regions

How it works

Two recognition paths

Input	Approach
Single-cell image (one letter in frame)	Machine learning on a 50×50 cell patch
Multi-cell photo (words or lines)	OpenCV dot detection → cell grouping → Grade 1 pattern decode

Both are handled in backend/braille/ml_detector.py.

Pipeline

flowchart TB
  subgraph input [Input]
    CAM[Camera or upload]
  end
  subgraph api [API]
    ML[ml_detector]
  end
  subgraph vision [Vision]
    DOT[Find dots]
    CELL[Group cells]
  end
  subgraph ml [ML]
    PKL[braille_classifier.pkl]
  end
  subgraph out [Output]
    TXT[English text]
    TTS[Speech optional]
  end
  CAM --> ML
  ML --> DOT --> CELL
  CELL -->|one cell| PKL --> TXT
  CELL -->|many cells| GEO[Pattern decode] --> TXT
  TXT --> TTS

Dot detection (OpenCV)

Contrast enhancement (CLAHE) and thresholding for dark dots and embossed relief
Contour filtering by size and roundness
Horizontal grouping into character cells using estimated dot spacing
Mapping each dot to positions 1–6 in a 2×3 cell, then to Grade 1 English

Machine learning

Model: scikit-learn MLP (1024→512→256) with StandardScaler
Training: scripts/train_model.py
Runtime: model loads on the API server; the web app calls REST endpoints (browsers do not load the .pkl directly)

Architecture

Data — merged training sets: Braille Alphabet Image Dataset (A–Z) (2,600 PNGs) and Braille Dataset (1,560 JPGs), 4,160 labeled cells total
Training — augmentation (flip, rotate, noise, blur), Otsu binarization, joblib export to models/braille_classifier.pkl
Vision — backend/braille/detector.py
Hybrid inference — ml_detector.py
API — FastAPI in backend/main.py (/scan, batch routes, WebSocket, static UI at /app)
Web UI — web/ (HTML, CSS, JavaScript)

Design notes

Early versions clustered dot rows instead of full cells; fixing pitch-based bucketing made multi-letter scans reliable. Single-cell ML works well on clean patches; photo crops look different, so multi-cell lines use geometric decoding. Image loading uses byte buffers and cv2.imdecode where file paths are awkward on Windows.

Roadmap

Grade 2 (contracted) Braille
Stronger models on real-world cropped cells (e.g. small CNN)
Mobile app with optional on-device inference
Glare and blur detection before capture
Community-contributed labeled photos

Problem statement

Physical Braille uses raised or ink dots in a 6-dot cell layout. BrailleVision:

Detects those dots in a camera image
Groups them into cells (two columns × three rows)
Decodes Grade 1 English
Optionally speaks the result

Repository layout

BrailleVision/
├── models/braille_classifier.pkl
├── web/                    # Web interface
├── backend/
│   ├── main.py
│   └── braille/            # detector, classifier, ml_detector, decoder
├── scripts/
│   ├── train_model.py
│   └── generate_sample_braille.py
├── Braille Alphabet Image Dataset (A-Z)/
├── Braille Dataset/
├── samples/
└── frontend/               # Optional React dev UI

Requirements

Component	Notes
Python	3.10+ (tested on 3.12)
Dependencies	`backend/requirements.txt`
Browser	Chrome, Edge, or Firefox (camera + speech)
Node.js	Optional, only for `frontend/`

A webcam or phone camera is enough; GPU is not required.

Quick start

Clone and install

git clone https://github.com/BoyTiger-1/BrailleVision.git
cd BrailleVision

Windows (PowerShell):

cd backend
python -m venv .venv
.\.venv\Scripts\Activate.ps1
pip install -r requirements.txt

macOS / Linux:

cd backend
python3 -m venv .venv
source .venv/bin/activate
pip install -r requirements.txt

Model file

The repository includes models/braille_classifier.pkl. If it is missing:

python scripts/train_model.py --augment 4

Run

cd backend
python main.py

Using the web app

Open /app/ and allow camera access if prompted.
Start camera, align Braille inside the corner guides, then Scan now or Live scan.
Or Upload one or more images.
Read the translation; use Read aloud or enable Voice guidance in preferences.
Toggle Detection overlay to see where dots were found.

API reference

Base URL: same host as the app (e.g. http://127.0.0.1:8000).

Endpoint	Description
`GET /health`	Status and model metrics
`GET /model/info`	Model version and classes
`POST /scan`	Multipart image upload
`POST /scan/batch`	Multiple files
`POST /scan/batch/base64`	JSON `{ "images": [...] }`
`WS /ws/scan`	Streaming frames

Example response:

{
  "text": "hello",
  "confidence": 0.95,
  "dot_count": 14,
  "cell_count": 5,
  "alignment_hint": "Good alignment. Hold steady for best results.",
  "debug_image": null,
  "per_cell_confidence": [0.99, 0.98, 0.99, 0.99, 0.97]
}

Training the model

python scripts/train_model.py --augment 4 --out models/braille_classifier.pkl

Flag	Meaning
`--augment 4`	Extra training copies per image
`--out`	Output path for the joblib bundle

The script discovers Braille dataset folders in the project root automatically.

Bundle contents: sklearn pipeline, label encoder, image size, classes, metrics, dataset list.

CLI test without server:

python backend/run_detect.py samples/braille_hello.png

Training data

Dataset	Location	Count	Format
Braille Alphabet (A–Z)	`Braille Alphabet Image Dataset (A-Z)/`	2,600	PNG 50×50, folder per letter
Braille Dataset	`Braille Dataset/Braille Dataset/`	1,560	JPG, label = first letter of filename

Merged training typically reaches ~99% held-out accuracy on single-cell images.

Accuracy and limitations

Scenario	What to expect
Clean single-letter images	Very high accuracy (ML)
Multi-letter synthetic samples	Reliable via pattern decode
Real camera, good lighting	Generally good; depends on focus and glare
Handwritten Braille	Variable
Grade 2 contracted Braille	Not supported yet
Unicode Braille text	Not supported (by design)

Typical latency: about 100–500 ms per frame on a laptop CPU.

Accessibility

Skip link to main content
Large touch targets and high-contrast theme
aria-live region for new translations
Web Speech API for optional read-aloud
Alignment hints when detection is weak

Troubleshooting

Issue	What to try
`Model not found`	Run `python scripts/train_model.py`
Camera blocked	Use HTTPS or localhost; check browser permissions
Scan failed	Confirm `/health` responds
Empty text	Better light, move closer, hold paper flat
Wrong letters	Reduce blur; keep paper parallel to the camera
