Arch Assistant: Building a Fully Offline AI Desktop Assistant

Inspiration

The idea for Arch Assistant was born from a simple frustration with the status quo of AI assistants. Every major AI service today—ChatGPT, Claude, Gemini—requires:

  1. A constant internet connection
  2. Sending your data to remote servers
  3. Ongoing subscription fees
  4. Dependency on service uptime

What if an AI assistant could be yours? Downloaded once, running entirely on your local machine, with zero recurring costs and zero privacy compromise? That's the question that drove every design decision in Arch Assistant.

The name "Arch" draws from two inspirations:

  • Arch Linux — the philosophy of user control, simplicity, and transparency
  • Architecture — the structural design of software systems that bridge multiple layers

What I Learned

Building Arch Assistant was a deep dive into systems integration across four fundamentally different technology stacks:

Electron + JavaScript (Frontend)

I learned to build desktop applications using Electron, where the renderer process (a Chromium browser) communicates with the backend through a local HTTP API on 127.0.0.1:9224. The key insight was using the Chrome DevTools Protocol (CDP) bridge pattern—Electron spawns a Python backend process that serves HTTP, and the frontend makes AJAX calls to it.

Python (Backend)

The backend runs on Python's standard library only (http.server, urllib.request, subprocess, json) because:

  • No pip install needed — runs on any system Python
  • Minimal dependencies reduce attack surface
  • Easy to debug and extend

Key patterns I implemented:

  • Server-Sent Events (SSE) for streaming AI responses token-by-token
  • ThreadingHTTPServer for concurrent request handling
  • Process management to start/stop the Ollama runtime as a subprocess

Ollama (AI Runtime)

Ollama serves as the local LLM inference engine. I learned to:

  • Run it in portable mode by setting OLLAMA_HOST=127.0.0.1:11435 and OLLAMA_MODELS to a local directory
  • Manage model manifests (.Modelfile files with custom system prompts)
  • Handle content-addressed blob storage where model weights are stored as sha256-<hash> files

Voice & Narration (TTS/STT)

I learned the difference between:

$$\text{Cloud TTS (Fish.Audio)} \rightarrow \text{High quality, requires API key}$$ $$\text{Browser TTS (speechSynthesis)} \rightarrow \text{Always available, lower quality}$$

The voice system uses a fallback chain: try Fish.Audio TTS API first (for premium voices), fall back to browser speechSynthesis if the API fails. Each voice maps to a Fish.Audio voice ID:

Voice Name Fish.Audio ID Browser Voice Mapping
Verity 8d21b053... Microsoft Zira (en-US)
Light 8e577d80... Microsoft David (en-US)
L 52d9d3c3... Microsoft Mark (en-US)
Sabrina 4cf07afc... Microsoft Zira (en-US)
Chinese Voice 95880cb6... Microsoft Xiaoxiao (zh-CN)

Software Packaging

I learned the complexities of distributing Windows applications:

  • Git LFS for large assets (model blobs can be gigabytes)
  • GitHub Releases as a CDN for the application archive
  • Batch file installers instead of unsigned .exe to avoid antivirus false positives
  • Portable design so the entire app can run from a USB drive

How I Built It

Architecture

┌─────────────────────────────────────────────────────────┐
│                Arch Assistant (Desktop App)             │
├─────────────────────────────────────────────────────────┤
│  Electron Frontend (Chromium)                           │
│    - index.html (UI, chat, voice settings)              │
│    - main.js (process management, window creation)      │
│    - voicebank/*.mp3 (voice preview samples)            │
│    - CDP Bridge: http://127.0.0.1:9224                  │
├─────────────────────────────────────────────────────────┤
│  Python Backend (portable, stdlib only)                 │
│    - api_server.py (HTTP server, SSE streaming)         │
│    - local_ai.py (Ollama client, model routing)         │
│    - ollama_runtime.py (process lifecycle)              │
│    - arch_context.py (config, paths, context)           │
│    - *.Modelfile (AI personality definitions)           │
│    - speech_stt.ps1 (SAPI dictation for voice input)    │
├─────────────────────────────────────────────────────────┤
│  Ollama Runtime (portable)                              │
│    - ollama.exe (local LLM server)                      │
│    - models/ (base model + persona manifests)            │
│    - lib/ollama/ (CPU backend DLLs)                     │
├─────────────────────────────────────────────────────────┤
│  Electron Binaries                                      │
│    - Arch.exe (main executable)                         │
│    - *.dll (Chromium/Electron runtime libraries)        │
│    - *.pak (locale/resource packs)                      │
└─────────────────────────────────────────────────────────┘

AI Model Architecture

The system is built on Qwen 2.5 Coder 3B (Q4_K_M quantization), which provides:

  • Parameters: ~3 billion
  • VRAM requirement: ~2 GB minimum
  • Context window: 4,096 tokens (optimized for speed)
  • Quantization: 4-bit (Q4_K_M) — reduces from ~6 GB to ~2 GB

Three AI personas share one base model:

$$\text{Base Model} = \text{qwen2.5-coder:3b-instruct-q4_K_M}$$

$$\text{Persona}_i = \text{create(Base Model, Modelfile}_i\text{)}$$

Where each Modelfile injects a custom system prompt:

# Luna.Modelfile (display: Terra 5.3)
FROM qwen2.5-coder:3b-instruct-q4_K_M
PARAMETER temperature 0.3
PARAMETER top_p 0.9
PARAMETER repeat_penalty 1.05
SYSTEM """
You are Luna, a helpful coding assistant...
"""

Voice Narration Pipeline

User clicks "Narrate" button
         ↓
speakOutLoud(text)
         ↓
voices.find(name === selectedVoice) → finds Fish.Audio voice ID
         ↓
speakFish(text, voiceId)
    Calls POST /api/tts {text, voice_id}
         ↓
Backend: fish_tts(text, voiceId)
    - Checks cache: sha256(voiceId|text) → temp/arch_tts_cache/
    - If cached: returns cached mp3
    - If not: calls https://api.fish.audio/v1/tts
    - Tries s2.1-pro first, falls back to s2.1-pro-free
         ↓
Audio plays via HTML5 Audio element

STT (Speech-to-Text) Pipeline

User clicks "Voice Input" button
         ↓
listenOnce(duration)
         ↓
POST /api/stt {duration: 5}
         ↓
Backend: Calls speech_stt.ps1
    - Uses .NET System.Speech.Recognition
    - SAPI dictation grammar
    - Recognizes speech via default audio device
    - Returns recognized text
         ↓
Text inserted into input field

Streaming Chat Architecture

The chat system uses Server-Sent Events (SSE) for real-time token delivery:

Frontend: POST /api/chat {messages, model, temperature}
         ↓
Backend: local_ai.chat_stream(messages)
         ↓
POST /api/chat (Ollama)
         ↓
SSE stream → yield {"role":"assistant","content":"..."}
         ↓
Frontend: EventSource processes each token
         ↓
Text rendered character by character

The streaming math:

$$t_{total} = \sum_{i=1}^{n} t_{token_i} + t_{network}$$

$$\text{Latency}{first} = t{prompt} + t_{first_token}$$

Where prompt processing is parallelizable but token generation is sequential:

$$t_{generate} = n \times t_{token} \approx n \times \frac{1}{tokens/second}$$

For Qwen 2.5 3B on a mid-range CPU:

$$tokens/second \approx 15-30 \text{ (CPU only, Q4)}$$

$$t_{response} \approx \frac{n_{tokens}}{20} \text{ seconds}$$

Challenges Faced

1. The Model Blob Problem

Ollama stores model weights as content-addressed blobs. Each 3B parameter model is ~2 GB. Including all model variants meant a 5 GB+ archive.

Solution: I pruned the blob storage to keep only the three active personas and the shared base model. Removed unused variants and old model versions:

Before: 5.2 GB (all model variants + blobs)
After:  337 MB (3 personas + base model skeleton, no blobs)
Final:  ~126 MB (compressed zip for distribution)

The models download on first run (background, ~2 GB total):

$$Size_{distribution} = \sum_{files \neq blobs} size_{file} = 126 \text{ MB}$$

$$Size_{runtime} = Size_{distribution} + \sum_{models} size_{blob}$$

2. Git LFS Misconfiguration

I initially tracked *.exe files with Git LFS, thinking the large Electron binary needed special handling. This caused the installer to become a 128-byte LFS pointer instead of a real executable—users would download a text file, not a program.

Lesson learned: LFS tracking rules can silently corrupt your releases. The fix:

# BEFORE (broken):
*.exe filter=lfs diff=lfs merge=lfs -text

# AFTER (fixed):
*.zip filter=lfs diff=lfs merge=lfs -text

3. Antivirus False Positives

The unsigned C# .exe installer triggered SmartScreen and antivirus warnings on every Windows machine—a common problem with unsigned executables that download and extract files.

Solution: Replaced the .exe with a .bat file that calls PowerShell internally:

  • Batch files are not flagged by AV heuristics
  • PowerShell's System.Net.WebClient is a standard .NET class
  • No dynamic code execution patterns

4. The ffmpeg.dll Error

When users ran Arch.exe directly (without the installer), Electron would crash with:

"The code execution cannot proceed because ffmpeg.dll was not found."

This happens because:

  1. Electron's DLL search path depends on the current working directory
  2. Running as administrator changes the working directory to C:\Windows\System32
  3. The ffmpeg.dll couldn't be found

Solution:

  1. The installer sets the shortcut's WorkingDirectory to the app folder
  2. The install.bat installs to %USERPROFILE%\Downloads\Arch Assistant (no admin needed)
  3. All DLLs are bundled in the same directory as Arch.exe

5. TLS/SSL Certificate Issues

The original installer used WebClient, which failed on some systems with SSL certificate validation errors when connecting to GitHub's CDN.

Fix: Switched to HttpWebRequest with explicit TLS 1.2:

ServicePointManager.SecurityProtocol =
    SecurityProtocolType.Tls12 |
    SecurityProtocolType.Tls11 |
    SecurityProtocolType.Tls;

6. The "UI Prototype" Fallback Message

During development, a placeholder replySimulated() function returned:

"Thanks for the details — this is a UI prototype, so this reply is simulated, but the flow (new chat → history → reopen) is fully wired up."

This was meant as a development fallback but appeared when the backend AI wasn't responding. Fixed by providing a helpful error message instead, so users know to check if Ollama is running.

7. Git History & Token Security

During development, GitHub tokens were shared in the development environment. After all work was complete, all tokens were revoked and the git history was checked for any accidentally committed secrets.

Technical Specifications

Component Technology Purpose
Frontend Electron + HTML/CSS/JS Desktop UI shell (~172 MB)
Backend Python 3.10+ (stdlib only) HTTP API, process management
AI Engine Ollama (portable) Local LLM inference
Models Qwen 2.5 Coder 3B (Q4_K_M) Language model backbone
Voices Fish.Audio API + Web Speech API Text-to-speech narration
STT Windows SAPI / .NET Speech Speech-to-text input
Installer Batch + PowerShell Download, extract, configure
Distribution GitHub Releases (126 MB) Application archive hosting

Performance Metrics

Metric Value
Distribution size 126 MB (zip)
Full install size ~350 MB (without models)
With AI models ~2.3 GB (3 personas + base)
RAM usage (idle) ~500 MB
RAM usage (chatting) ~1.5-2 GB
First token latency ~5-15 seconds (model load)
Steady-state token rate 15-30 tokens/sec (CPU)
Voice narration latency ~2-5 seconds (TTS)

What's Next

  • [ ] Auto-updater — Check for new releases on startup
  • [ ] GPU acceleration — CUDA support for faster inference
  • [ ] Plugin system — Allow custom tools and extensions
  • [ ] Multi-model support — Switch between different base models
  • [ ] Voice commands — Wake word detection + voice-only control
  • [ ] Mobile companion — Remote access to the local AI from phone

Key Files

File Purpose
install.bat Bootstrap installer (no admin, auto Python check)
Arch.exe Electron executable (bundles Chromium)
api_server.py Python HTTP server (CDP-style bridge on :9224)
local_ai.py Ollama client, streaming chat, TTS/STT
ollama_runtime.py Portable Ollama process management
arch_context.py Config loader, paths, runtime context
*.Modelfile AI personality definitions (Terra 5.3, Chen Instruct 3, Fable 5.1)
speech_stt.ps1 PowerShell STT script using SAPI (deprecated, replaced by Web Speech API)
index.html Frontend UI (HTML + CSS + JS, ~180K lines)
main.js Electron main process (window, backend spawn)
voicebank/*.mp3 Voice preview samples for settings
ollama/ Bundled Ollama runtime + base model manifests

Built with persistence, curiosity, and a belief that AI should be accessible to everyone — not just those with fast internet and cloud subscriptions.
