MR Blueprint: Draw Physics Into Reality

Inspiration

We were inspired by the idea that spatial computing should not just visualize the world — it should let you author behavior inside it.

Most XR creation tools focus on drawing geometry or sculpting models. We wanted to explore a different paradigm: drawing physics itself.

The Logitech MX Ink stylus introduces a level of precision (pressure, tilt, tip contact) that makes it possible to map physical meaning directly to gestures. This opened the door to a new interaction model where users draw forces, constraints, and systems instead of menus or UI panels.

Our goal became simple:

What if anyone could turn their room into a physics laboratory in seconds?

What it does

MR Blueprint is an augmented reality physics simulator running on the Meta Quest 3. Users can place virtual objects into their real environment using passthrough mixed reality and then draw interactions between them using the MX Ink stylus.

Instead of configuring physics through menus, users sketch behaviors directly:

Draw a line between objects → spring constraint
Press harder → increased stiffness
Draw a circle → hinge joint
Draw a boundary → collision wall
Flick objects → impulse forces

The real room becomes part of the simulation space.

How to build it

The project is built using Unity with XR and physics systems.

Key systems included:

Mixed Reality room setup using Quest spatial anchors
Real-time constraint generation from stylus strokes
Mapping stylus pressure to physical parameters
Unity rigidbody physics for simulation
Gesture interpretation pipeline for converting strokes into constraints
Runtime visualization tools for forces and boundaries

The project implements a simplified spring system based on Hooke’s Law:

$$ F = -k(x - x_0) $$

Where:

$$k$$ is derived from stylus pressure
$$x_0$$ is determined by stroke length
Direction comes from stylus orientation

This allowed users to “feel” the physics while drawing.

Challenges we ran into

One of the biggest challenges was translating freeform drawing into deterministic physics behaviors. Human strokes are noisy, so we had to design interpretation rules that felt intuitive while remaining stable.

Other challenges included:

Mapping stylus input meaningfully to simulation parameters
Maintaining simulation stability with dynamically created constraints
Aligning virtual objects convincingly with real-world geometry
Designing interactions that were understandable within seconds

We also had to balance realism with responsiveness to keep the experience playful and educational.

What we learned

We learned that precision input dramatically changes how users think about spatial computing.

Instead of navigating menus, users naturally experimented — almost like playing with real objects.

We also discovered that drawing behavior instead of geometry is a powerful mental model that could extend beyond physics into robotics, game design, and engineering education.
